2×8 for joists will be fine, with 16″ OC. Should use 2×10 for beams but 2×8 will be fine as well. If you are worried you can triple the 2×8 for the beams but double will be sufficient. You should put the beams at 7 and 14 feet out from the house, with the piers you should do 3 per beam with spacing of 1, 7, 13.

How far can you span a 2x8 floor joist?

Maximum Span (ft – in)Nominal Size (inches)Joist Spacing Center to Center (inches)Lumber Grade2 x 81215′ – 10″1614′ – 5″2412′ – 4″

What is the maximum span for a 2x6 deck joist?

2-grade 2×6 joists can span up to 10 feet 9 inches from beam to beam when spaced the standard 16 inches apart with a maximum live load of 30 inches per square foot.

Should deck joists be 2x6 or 2x8?

For upper-level decks, 2×10 is recommended as the minimum size to use for strong guard post connections. 2×6 joists should only be used on ground-level decks that do not require, and will not provide for, any guards. … Most decking is not strong enough to support longer spans than 16″.

How far can a 2x8 span without support?

But first, generally, how far can a 2×8 span without support? Depending on various factors, the maximum span for a 2×8 floor joist is 16′ 6”. The maximum span for roof rafters is 23′ 9”. For headers, the maximum span is 11′ 2”.

Will a 2X8 span 12?

A rule of thumb is 1.5 times a joist’s depth but in feet when spaced at 16” centers. In general, a 2×8 will span 1.5 x 8, so 12-feet.

How much can you cantilever a 2x8?

The American Wood Council states that cantilevers are limited to 1/4 the span of the joists. Joist Spacing (o.c.) Maximum allowable overhang cannot exceed 1/4 of the actual main span.

How far can you span a 2x10 deck joist?

A 2×10 beam – made up of two 2x10s nailed together – can span up to 11′ without support beneath a deck that is 4′ wide. For a more normal-sized deck, the same beam can span 8′, supporting a deck that is 8′ wide. You can also triple a 2×10 beam.

How much load can a 2X8 support?

Span (feet)Weight Supported (lb)2 x 2″ x 6″2 x 2″ x 8″42250469061680313082660

Can I use 2x8 for deck boards?

Q: Can I use 2×8 treated lumber as deck boards? A: No, that’s a not a good idea. Lumber wider than 6 inches should not be used as a flat surface. Wide, flat boards have a tendency to pool rain water, which can lead to cupping problems.

Article first time published on

How far apart should deck blocking be?

1. Space. Solid wood blocking should be equally spaced in rows, with a maximum of 4′ to 6′ apart.

How many joists do I need for a 16 foot deck?

For example, when you space joists 16″ apart — which is standard for residential decks — a deck spanning 9 1/2′ would require 2-by-6 joists, a 13′ deck would need 2-by-8 joists and a 16′ deck calls for 2-by-10 joists.

How many footings do I need for a 12x16 deck?

A standard deck will need four footings parallel to the house, but they will need to be temporarily braced by 6 inch-by-6 inch posts. Using doubled boards, you will then need to build beams on the top row of the posts to frame the edges of the deck. These must be topped with adjustable post caps.

How far apart should support beams be on a deck?

Deck joists are typically spaced either every 12 inches or 16 inches on center. The maximum joist spacing you can use will depend on the size and allowable span of your joists.

What is the maximum span for deck joists?

Decking boards span from joist to joist. If you use 5/4 decking, joists must be no farther apart than 16 inches. Decking made of 2x4s or 2x6s can span up to 24 inches. If you will run decking at an angle, you might need to put the joists closer together.

How much should a deck overhang?

The edge of decking should never overhang more than one-third of the decking material. For your standard 5.5” decking, that is 1 ¾” overhang.

How far can you cantilever a 2x8 deck joist in Ontario?

3. Maximum cantilever (overhang) for 2″ x 8″ joists is 16″ and for 2″x 10″ joists is 24″.

How far can a deck beam cantilever over a post?

The American Wood Council’s Wood Frame Construction Manual states that beams can generally cantilever up to 1/4 their span over a post.

How much does a 2x8 weight per foot?

Weight of Dimensional Lumber2 x 61.5 x 5.52.342 x 81.5 inch x 7.25 inch3.09 lbs2 x 101.5 x 9.253.952 x 121.5 x 11.254.80

Does double joists increase span?

For example, if you double the thickness or number of joists in a floor, the distance the boards can span will increase by approximately 25%. But if you double the width of the boards, the distance the joists can span increases between 80% to 100%, even though you’re using the same board feet of lumber.

How long can joists span?

How Far Can Floor Joists Span? A floor joist can span nearly 26′ in the most extreme cases. A select douglas fir 2×12 supporting a 30 psf live load and 10 psf dead load, spaced at 12” will have the greatest span length.

What is 2x8 lumber used for?

2×8 Yellow Pine Lumber, #1 Grade, S4S Kiln-dried and #1 framing grade. This board is a more economical choice and often used for construction, rustic furniture making and bed frames. Boards are S4S where both side and edges are planed smooth.

What size wood should I use to build a deck?

For the deck surface, you can use 2x4s, 2x6s, or 5/4x6s. The 5/4 decking (pronounced “five-quarter”), available in cedar and pressure-treated fir, is 1 inch thick and 5-1/2 inches wide with rounded edges that make for a splinter-free surface. Cedar 1x lumber usually has one rough side and one smooth side.

How thick should joists be on a deck?

Decking TypeActual Thickness (inches)Suggested On Center Joist Spacing (inches)Tropical Hardwoods 1×13/16”16”Thermally-Modified 5/41”16”Pressure Treated Pine 5/41”16”Western Red Cedar 5/41”16”

Where do you put blocks on a deck?

One of the most popular ways to install deck blocking is to snap a chalk line across the center of your joists and install the blocking on alternating sides of the chalk line. This is done to allow direct nailing of each block.

Do you leave a gap between decking?

Proper Gap between Decking Boards When installing decking boards, make sure to leave 1/4 to 1/8 inch gaps in between them. This gap will make sure that the decking can breathe, have sufficient drainage, and make it easier to clean.

How level do deck joists need to be?

Remember, you are looking for consistency between joists of less than 1/8” (3mm). A discrepancy of less than 1/8” (3mm) will not be noticeable on the deck and is hard to see from the edge of the deck. The easiest is a straight board or 6′ level, but a string line is more accurate.

How far can a 2x8 span for a roof?

Maximum Span (ft – in)Nominal Size (inches)Rafter Spacing, Center to Center, OC (inches)Lumber Grade2 x 62413’2 x 81221′ – 7”1619′ – 7”

Can I use deck pier blocks instead of footings?

Pier blocks can be used instead of footings for a ground-level deck not requiring permits. Piers blocks can also be used if the frost level depth is less then the height of the pier block.

What is the maximum distance between deck posts?

Ideal deck post spacing is 8 feet or less. The distance between deck support posts depends on the type of wood species used and the size of the joist and beam. There is no minimum span, and maximum spans can reach up to 15′.

How many posts are needed for a 12x12 deck?

Before starting to build, the first question is: How many footings do I need for a deck? For an attached 12 x 12′ deck, you’ll need at least 3 footings, plus at least 2 more if you’re planning on building stairs with it.
