If it is mashed or one of the wires is broken off right at the thermocouple then you’re going to have get a new one – that kind of thing can’t be fixed. … The bare wires can get shorted just by bending them. They can also get twisted and short out.

Can you clean thermocouple?

Yes, you can clean a thermocouple, but the task must be done with a light touch. Remove the thermocouple from the process assembly, using a steel wool or emery cloth, lightly clean the tip removing any build up.

How do I reset my thermocouple?

Press the reset button on top of the box to turn on the pilot light. Hold the reset button between 30 to 60 seconds to give the thermocouple time to heat up. Release the button to see if the pilot light goes out. The pilot light should stay on after the reset.

How do I know if my thermocouple is bad?

If you can’t get the flame to light at all, and you’re sure the gas is on, there’s probably an obstruction in the pilot tube. If the flame lights and goes out when you release the gas control knob after holding it in for the recommended 20 to 30 seconds, that’s the sign of a thermocouple malfunction.

How do you bypass a thermocouple?

1. Move the tilts switch wire aside.
2. Remove your thermocouple from the heater using an 8mm wrench.
3. Pull the valve housing aside using your 13mm socket wrench. …
4. Remove the valve using your pliers. …
5. Put your thermocouple back into position.

Is a flame sensor and thermocouple the same thing?

People tend to use the terms “flame sensor” and “thermocouple” interchangeably. In truth, while they basically perform the same job, they’re not the same thing. If your furnace uses an electronic controller, it’s got a flame sensor. Thermocouples are used on standing pilot furnaces that have pilot lights.

Should thermocouple be in pilot flame?

If the pilot light goes out, the thermocouple detects it and shuts the valve supplying gas to the pilot. The pilot flame should touch the thermocouple at a specific level. … If the flame covers the top of the thermocouple and burns steadily with a yellow tip, that’s just about right.

How do you clean a thermocouple sensor?

The best way to clean your thermocouple is to use either a piece of steel wool or the coarse side of a sponge to gently clean off any soot or other remnants. You can use a pencil eraser to clean between the threads of the screw that connects the thermocouple to the control valve of your system.

How long do thermocouples last?

How to Tell if You Have a Bad Thermocouple? Thermocouples can last up to 10 years if properly installed and maintained, while furnaces can last 15-20 years, although either may wear out sooner in multifamily units.

Can a thermocouple work intermittently?

In electrical circuits, the most unreliable points are electrical connections. So, if in a thermocouple circuit any of the connections suffer from corrosion or lack of intimate metal-to-metal contact, intermittent operation will result.

Article first time published on

Will a pilot light on a thermocouple go bad?

A thermocouple senses the heat of the pilot and allows gas to flow to the burner. A bad thermocouple will shut off gas to both the pilot and the burner so the pilot light won’t stay lit.

Are thermocouples universal?

Honeywell, White Rodgers, and other manufacturers make universal replacement thermocouples, usually with a 30-millivolts (mV) rating for standing-pilot furnaces. … Electronic flame sensors are much less universal, and you must find the exact part specified for your furnace model.

Why does my thermocouple keep going bad?

Changes in temperature can cause regular expansion and contraction in metal, which will cause thermocouples to weaken over time. After enough time, metal fatigue can cause a thermocouple to break. … If thermocouples start to give out unusual readings, it may be suffering from metal fatigue.

Can you bypass thermocouple on furnace?

Realistically, you have just disabled the thermocouple, but you can also reach in and unclip it from its holding bracket where it meets the pilot light. In most cases it will be held on with a gravity clip, but some are held on with a screw that must be removed with a small screwdriver.

Why won't the pilot stay lit on my wall heater?

The Pilot Won’t Stay Lit A pilot that won’t stay lit could be the result of a blockage in the pilot tube. Turn off the gas, clear the tube with compressed air, and relight the pilot. If that doesn’t work, you may need to call a repairman to come and install a new thermocouple.

Why is my pilot light not staying lit on my furnace?

Some common causes include issues with the thermocouple and pilot tube. The thermocouple detects the pilot light via sensors. … A dirty pilot tube can also prevent the pilot from staying lit. If the pilot tube is dirty, let the furnace cool down and turn off the gas.

Are all thermocouples the same?

From an operational perspective the thermocouples for a water heater are all pretty much the same. However, there are two variables, the length and the fittings used to install them, see below. A failing thermocouple will not send the correct electrical impulse and the gas valve will not release any gas.

What color should pilot flame be?

Inspecting a Gas Furnace Pilot Light Flame A natural gas flame should be a bright blue color with a small amount of yellow at the very tip. A propane flame will have more of a bluish-green flame with a tinge of yellow at the tip. The flame should strong enough to cover about 1/2 inch at the end of the thermocouple tip.

Why is my pilot light flame yellow?

The most common reason why a pilot light would start to burn yellow is that the air intake valve to the pilot light is clogged with dirt. … If there is a small amount of dirt blocking the air, the yellow color might only be at the tip of the flame. If there is a large amount of dirt, the entire flame will burn yellow.

Why does my pilot light flicker?

If you find that your pilot’s flame is flickering and is mostly yellow, this means that there is too much air in the gas line. … As the air flows into the line, the flame is not able to burn enough gas to burn hot and steady. Second, the furnace’s thermocouple may be broken.

What happens when flame sensor goes bad?

What happens when a flame sensor goes bad? … If your flame sensor is dirty or faulty, it will automatically shut down the heating unit if it doesn’t detect a flame. Most furnaces will go into a safety ignition lockout when a shutdown happens three times.

How much is it to replace a thermocouple?

It costs $150 to $250 to replace a thermocouple. It checks to make sure the pilot light is on. It will shut the gas off if it’s not.

Does a thermocouple have mercury in it?

There are several types of non-mercury-containing thermometers, including both liquid-in-glass and electronic digital thermometers. An example of an electronic digital thermometer is the platinum resistance thermometer. Others include the thermistor and the thermocouple.

What uses a thermocouple?

Thermocouples are used in applications that range from home appliances to industrial processes, to electric power generation, to furnace monitoring and control, to food and beverage processing, to automotive sensors, to aircraft engines, to rockets, satellites and spacecraft.

Can you sand a thermocouple?

Water Heater Thermocouple Cleaning in 5 Steps This is always the first step when working on a water heater. … Clean the thermocouple – using the emery cloth sandpaper, sand the ends of the thermocouple and then give it a finishing touch with the lint-free cloth.

How do you clean a gas log thermocouple?

1. Turn off the fireplace gas valve and remove the front panel from the fireplace. …
2. Find the thermocouple, which is located next to the pilot light and looks like a small straight pipe.
3. Use a can of compressed air to gently blow away any dust and dirt from the thermocouple.

How many volts does a thermocouple produce?

A single thermocouple (C Type) is used for a standing pilot system and generally produces around 30 millivolts. This voltage is used by the gas valve to keep the pilot valve solenoid internal to the main gas valve open.

Why does my gas logs keep going out?

Drip Loop: moisture in the gas line can cause a failure in the drip loop. This could be the reason why your fireplace won’t stay lit. Moisture can dilute the natural gas, so you’ll want to have a professional see if this is the problem at hand.

Do Thermopiles go bad?

Like the other component parts in your furnace, the thermocouple can wear down over time, producing lower voltage than it should when heated. And the worst part is that you can have a bad thermocouple without even knowing. Therefore, inspecting and testing your thermocouple should be part of your furnace maintenance.

Why does my pilot light go out when I release the pilot light knob?

The most likely of those is that the thermocouple needs to be replaced. The button you press to light the pilot bypasses the thermocouple. When you release the button, the thermocouple ensures that unburned gas doesn’t get released by shutting off the gas when it’s not heated by the burning pilot light.

Do all water heaters have thermocouples?

Not all gas water heaters have a thermocouple. Some newer models have an advanced temperature control system. Essentially, it is a microprocessor that constantly monitors and controls burner operation and maintains consistent and accurate water temperature levels. The flashing LED indicates that the pilot is on.
