The width of the roller shutter is measured from the outside of the window from brick to brick (as shown in the picture). It is measured at two places. First at the top of the window and at the bottom of the window. If both the measurements are different, just take the smallest measurement out of the two.

What is the unit of measurement for rolling shutters?

The rolling shutter is measured in terms of area in square m (SQM), the payable area shall be obtained from the net opening for which the rolling shutter has been provided.

What is the height of rolling shutter?

Height: 12 feet. Thickness: Upto 5 mm. Material: Aluminium. Width: 10 feet.

How are existing shutters measured?

Window WidthShutter Width32″ – 40″14.5″-16.25″-17.75″

How do you measure for security shutters?

1. Begin by measuring the inside width of the opening. …
2. Take the height of the opening. …
3. Measure the amount of space above the opening where the rolling security shutters will be installed. …
4. Measure the space on both the right and left sides of the opening.

How do you choose shutter size?

Shutter size should be between 25-50% of the window width in order to remain aesthetically pleasing. Never install house shutters that are wider than the window.

What is the thickness of shutter?

Shutter stiles shall be a minimum of 2-5/8 inches wide by 1 3/8 inches thick. Top rails and midrails shall be a minimum of 2 3/8 inches wide by 1 5/16 inches thick. Bottom rails shall be minimum 4 1/8 inches wide by 1 3/8 inches thick.

Can you put shutters on double windows?

Shutters should be avoided on double-mulled windows, picture windows, bay windows, and most dormer windows.

How do you measure for Batten and board shutters?

Measure. For working shutters, to find the width of each one, measure between the window’s side casings, divide by 2, and subtract ½ inch for clearance. Then, to find the width of the boards, subtract ⅛ inch for each gap and divide by the number of boards—four in our case.

How do you calculate rolling shutter weight?

How do you calculate the weight of the rolling shutter? An easy way to estimate the weight of the shutter is by the square feet, usually a shutter with slats in 20 Gauge thickness weigh about the same as the square feet. For example, a shutter of size 8 feet height x 8 feet width would weigh roughly 64 kg.

Article first time published on

Is standard for rolling shutter?

Rolling Shutter As Per IS Code 6248.

What is the ideal thickness of lock rail in a door shutter?

(v) The lock rail is so placed that its centre line is at height of 800 mm from the bottom of the shutter. (vi) The stiles and the rails are mortised and tenoned. (viii) The thickness of plywood should not be less than 10 mm.

How much do aluminium shutters cost?

Aluminium window shutters: Perfect for weathering all conditions, aluminium shutters are ideal for outdoor use. Expect these to cost $350-$450 per square metre.

How much do American shutters cost?

Plantation shutters cost anywhere from $70 to $420 per window, depending on many factors such as where you buy them, whether they’re custom-built, and the material they’re made from. According to HomeGuide, the national average cost to get plantation shutters installed is $2,350 total.

How secure are American shutters?

AMERICAN shutters ® Aluminium Security Shutters Exceptional safety, durability, and sophistication; our Security Shutters offer both security and style. The aluminium louvres fit snugly to provide privacy and light block when desired, and, when opened, allow in natural light.

How thick are plantation shutters?

There are a number of louver sizes available for custom plantation shutters. The size of louver you pick will depend on what style you want for your window. Choose from 1 7/8, 2 1/2, 3 1/2 and 4 inches. Larger louver sizes help give your window a more modern, contemporary look.

What wood should I use for shutters?

While cedar is the common choice among homeowners when it comes to choosing materials for exterior shutters, there are many people that prefer redwood and cypress as well. Redwood and cypress are mainly used for shutters that require high-end installation. Redwood is also resistant to bugs, decay, and moisture.

How thick should louvers be?

The thickness of louvers generally ranges from ¼†up to ½ inch. Louver Style: The style of a plantation shutter louver refers to the shape or profile of the shutter louver. Generally there are two different styles, flat and elliptical.

Should shutters be length of window or trim?

In most cases, the height of decorative shutter that is most appropriate is from the top to the bottom of the window trim. If there is a sill at the bottom of the window and you are installing vinyl shutters, it is important to leave a gap of at least 1/4 inch to allow the vinyl material to expand and contract.

How do I choose a shutter?

Make sure that the shutters fit your windows. Each shutter should match the length of the window (excluding trim) and be approximately one-half of the windows width (again excluding trim). Also, think about spaces between windows when measuring for shutter widths.

How do I choose the right shutters?

1. Consider Your Home Improvement Needs. …
2. Compare available Shutter Styles. …
3. Choose the Best Shutter Materials. …
4. Correct Shutter Sizing is Key. …
5. Choose Shutters to Flatter Your Windows.

What kind of wood is used for board and batten shutters?

Western Red Cedar is the most common material for building exterior board and batten shutters in the industry. Cedar has many of the same qualities as Redwood, yet is less dense, making it easier to sand and finish.

How wide should board and batten be?

The battens should butt tightly against the top trim board and be flush at the bottom with the wider vertical boards. While the width of the battens is your choice, they should be wide enough to overlap the edges of the larger boards by at least ½ inch on both sides.

Are shutters out of style 2021?

Window Treatment Styles And Designs That Are Out in 2021 Speaking of shutters, gray and gray-tone wood grain is rising in popularity for shutters, with all-white and dark wood shutter stains declining in popularity.

Are outdoor shutters in Style 2020?

They allow light and air and also offer protection from storms and are a great choice for homes in tropical regions. So, when the question ‘are exterior shutters still in style’ comes to your mind, the answer is ‘Yes‘. No other exterior decorative elements can beat the flexibility and smoothness of these shutters.

Are shutters on houses outdated?

According to All About Shutters, shutters are believed to have originated in ancient Greece to control light and ventilation both inside and outside of dwellings and buildings. Today, shutters are used extensively all over the world, for functional and aesthetic purposes.

How much does a roller shutter weigh?

ProductWidth (inc guides)Curtain weight (rounded up per kg)Viewguard 20g6000 mm10 kg/m2Screenguard 22g4500 mm10 kg/m2Screenguard 20g6000 mm12.5 kg/m2K90 (solid aluminium)4500 mm10 kg/m2

What is the weight of roller shutter?

SizeWeight16 SWG (1.50 MM)-14 SWG (2.00 MM1.100 Kg per Rft12 SWG (2.50 MM)1.400 Kg per Rft10 SWG (3.15 MM)1.750 Kg per Rft

How much does a roller door weight?

Garage doors are available from 18-gauge for some commercial models to a standard 25-gauge in residential doors. Single car steel doors weigh near 85-130 lbs while double doors weigh between 150-225 lbs.

Is code for steel rolling shutter?

FIG. 6.1 Cold-Rolled Steel Strips – Cold-rolled steel strips used ibr rolling shutter lath szctions shall conform to temper No. 5, Dead soft quality of IS : 4030-1973*.

Where are rolling shutter doors used?

Roller shutters have many applications including doors for vans, garages, kitchens, schools, prisons and warehouses. They are also commonly used as window blinds in some European countries, such as Germany and Spain. In some parts of the world, roller shutters are subsidized by local governments.
