Ratings for fire resistance are given in accordance to the time a structure can contain a simulation fire. More specifically, if a wall is constructed in a manner that closely resembles a tested wall which has shown to contain flames and high temperature for one hour, it is eligible to receive a 1-hour rating.

What is 1 hour fire rated drywall?

The 5/8-inch, “fire-code” drywall (called Type X) increases a wall’s fire rating to a minimum of 1 hour, from the 30-minute rating for standard ½-inch drywall. And it’s not just thickness that makes the difference. Type X has a denser core and contains glass fibers that keep it from crumbling in the heat.

What does 1 hour fire rating mean?

A “one-hour” fire rating is given to an assembly consisting of various building materials that can resist the exposure of a standardized fire exposure for one hour. … A few acceptance criteria for the test stipulate that the fire from the gas-fired furnace cannot penetrate through the assembly during the test.

What makes a wall a fire wall?

A firewall is a fire-resistant structure which restricts the spread of fire and extends continuously from the foundation to or through the roof with sufficient structural stability under fire conditions to allow the collapse of the existing construction on either side of the wall to occur without allowing the collapse …

What is the fire rating on 1 2 drywall?

The fire rating for the 1/2-inch drywall used throughout the rest of the home is 30 minutes. As added benefits, Type X absorbs sound slightly better and is slightly stronger than conventional 3/8-inch or 1/2-inch drywall.

How do I know if my wall is fire rated?

The total fire rating is determined by adding each component to reach a minimum total of 60 minutes. Fire protection rating is calculated from the flame side of the assembly and of course some assemblies have multiple flame sides. Your wood framing members are required to be not more than 16″ on center.

What are the 3 main classifications of fire rated walls?

Type 1: Fire resistant: tall buildings protected by concrete and steel. Type 2: Non-flammable: New buildings with pitched roofs or reinforced masonry walls and metal roofs. Type 3: Ordinary: new or old buildings, with non-combustible walls, but a roof with a wooden structure.

What constitutes a 2 hour fire wall?

Gypsum Board: Two (2) hour rated walls have two (2) layers of 5/8″ Type ‘X’ gypsum wallboard panels on each side of the steel studs. The “Fire Tape” product would be used as an alternative to conventional joint tape in specific systems when: 3.

Is all gypsum board fire rated?

All gypsum panels are fire resistant and produced in a range of thicknesses, core formulations and optional special performance enhancements. … In Type C panels, the core is enhanced with glass fibers as well as other additives to provide an even higher level of fire-resistance than Type X panels.

What is a 2hr fire wall?

Double the number of Type X sheets on the wall for a simple system installed over fire-resistant fiberglass insulation; each sheet of 5/8-inch Type X drywall is rated to resist fire for one hour, so two layers will produce a two-hour firewall. Put two sheets together on one side or use one sheet on each side of a wall.

Article first time published on

What is the difference between a fire barrier and a fire wall?

Basically, firewalls are thick exterior walls with a higher fire-resistance rating, while fire barriers are interior walls with a lower fire-resistance rating.

What is a 0 hour fire rated wall?

In certain types of buildings Fire Separations are considered to have wall Fire Separations with 0 hour fire rating. These walls are considered smoke separations to prevent smoke from migrating throughout the building.

What plasterboard gives 1 hour fire protection?

Gyproc FireLine 12.5mm is a fire resistant plasterboard that withstands fire for longer to allow for safe evacuation.

Is a firewall required between garage and house?

In short, the garage needs to be separated from the house in case of fire, but this isn’t a fire-rated assembly, nor is it a firewall. The best term for this required separation is a fire-separation wall.

What makes drywall fire rated?

The gypsum used to make drywall is a naturally occurring mineral composed of calcium sulfate dehydrate and water. The presence of water in gypsum contributes greatly to drywall’s natural fire resistance. … This type of failure permits the passage of fire and heat into the substrate material and beyond.

How thick is a 2 hour fire rated wall?

A 2-hour rating can be achieved by a wall with an equivalent thickness of as little as 3 1/5 inches when expanded slag or pumice is used or 4 1/2 inches when siliceous gravel is used as the aggregate. For cored units, the equivalent wall thickness is calculated by multiplying the percent solid by the wall thickness.

How thick is a 3 hour fire rated wall?

CONCRETE TYPEMINIMUM SLAB THICKNESS (inches) FOR FIRE-RESISTANCE RATING OF1 hour3 hoursSiliceous3.56.2Carbonate3.25.7Sand-lightweight2.74.6

What is the difference between Type 1 and 2 construction?

Type 1: Fire-resistive: High-rise buildings made of concrete and protected steel. Type 2: Non-combustible: Newer buildings with tilt slab or reinforced masonry walls and a metal roof.

How is fire-resistance rating determined?

The fire-resistance rating of a wood frame assembly is equal to the sum of the time assigned to the membrane on the fire-exposed side, the time assigned to the framing members and the time assigned for additional contribution by other protective measures such as insulation.

How do you determine fire rating requirements?

Fire-resistance ratings are determined by testing a mock-up structural assembly according to procedures in the American Society for Testing and Materials (ASTM) E119 Standard Test Methods for Fire Tests of Building Construction and Materials, available at The test also is known as NFPA 251, Standard …

What walls should be fire rated?

Exterior walls shall be fire-resistance rated in accordance with Tables 601 and 602 and this section. The required fire-resistance rating of exterior walls with a fire separation distance of greater than 10 feet (3048 mm) shall be rated for exposure to fire from the inside.

Is drywall mud fire rated?

Design Studio Joint compound does not have a fire rating by itself, but does meet ASTM C475. When fire testing a wall the fire rating is not for individual products, but for all the system components together. USG Joint Compounds are used in numerous fire-tested assemblies.

Is regular drywall fire rated?

Drywall is relatively fireproof, but manufacturing processes such as adding glass fibers can increase the resistance. Drywall is relatively fire resistant. It’s composed of gypsum pressed between two sheets of thick paper.

Is cement board fire rated?

Yes, HardieBacker® 1/4” Cement Board is deemed noncombustible when tested to ASTM E 136 and can be used in conjunction with other noncombustible materials around a fireplace. This does not mean that clearances to combustible building materials can be reduced by using HardieBacker 1/4″.

How many layers of drywall do I need for a 2 hour rating?

As 2 hours of fire protection has become the standard for fire safety in America, it has become somewhat of a standard practice to include two layers of type X drywall within a building’s perimeter in order to achieve this required level of fire safety.

What is the difference between a 1 hour fire partition and a 1 hour fire barrier?

In reference to the term “barrier”, the IBC is very specific that a “barrier” must have a minimum 1 hour fire resistance rating. … A “partition” has a fire resistance requirement of 1 hour minimum as well.

Which type of walls act as barriers to fire spread?

Fire barrier walls are typically constructed of drywall or gypsum board partitions with wood or metal framed studs. Penetrations – Penetrations through fire walls, such as for pipes and cables, must be protected with a listed firestop assembly designed to prevent the spread of fire through wall penetrations.

What is a fire separation and how does it relate to fire resistance ratings FRR of materials?

However, fire separations are assemblies that may or may not be required to have a specific fire-resistance rating, while structural members such as beams and columns that require a fire- resistance rating to maintain the structural stability of a building in the event of a fire are not fire separations because they do …

What is the fire rating of a material?

A combustible material will be rated as Class A, Class B, or Class C based on its performance in this test. A material rated as Class A would have a lower flame spread, and therefore a better performance rating, than a Class C material. The results of the flame spread test results in a numeric rating.

What is flame spread rating of 25?

A numerical reference that measures how fast and far a flame spreads during a 10-minute test. Flame Spread Index of 25 or less; the best possible rating, awarded to fire-retardant building products, like concrete.

Is 12.5 mm plasterboard fire rated?

If the ceiling is plasterboarded, then 12.5mm thick boards are required to give 30 minutes’ fire resistance. You may have to provide an additional skim coat or additional plasterboard to the ceiling.
