If the “Inspect Cell” light flashes by itself it is an early indication that the salt generator needs a manual reset. Each cell is equipped with 500 operational hours and requires a manual reset once it expires. To reset the cell, hold down the “Diagnostic” button for 3-5 seconds.

How do you reset a salt water generator?

To reset, move the switch to ‘Off’ and then back to ‘Auto’. Wait for the relay to click (5 to 10 seconds). When the instant salt level is stable (and the negative sign still present), slide switch to ‘Super Chlorinate’ and back to ‘Auto’. It takes about 30 seconds for the unit to settle back on the default reading.

What should my salt generator be set at?

We suggest you start your salt chlorine generator at 50 percent output and run it for a couple of days, then check the chlorine level. In a balanced pool, a good chlorine level is 1-3 parts per million. If your chlorine levels are low, you can raise the percentage, and if it’s high you can lower the percentage.

Why is my salt generator not working?

The saltwater chlorinator needs a sufficient flow of water for effective operation. A dirty skimmer basket, clogged or dirty filter, and a clogged pump strainer, can cause insufficient water flow for the chlorinator to produce less chlorine.

Why is my salt generator not producing chlorine?

Salinity. Chlorine generators need salt to produce chlorine and can’t do so if the amount of salt in the water is too low. The desired salinity level in a saltwater pool is between 2,500 and 3,500 ppm. … If your salinity is below 2,500 ppm, the generator will not be able to produce chlorine.

How do I know if my Pentair salt cell is bad?

1. The power center displays a Check Salt message. …
2. The Cell Warning light displays consistently, shutting off for only a short while after cleaning.
3. Voltage is higher than normal.
4. Amperage is irregular (it should normally be zero or just slightly above)

How do you recalibrate a Hayward Salt Cell?

Turn Salt System Off and On With the pump running, take the power switch down to the “Off” position, and then back up to “Auto”. You should hear a click within 10 or 15 seconds. When you do, press the diagnostic button five times in a row. The system will go through a recalibration process.

Why does my chlorinator says no flow?

The most common reason for low or no flow is that the baskets are full of debris. … *Always turn the pump off before you remove the baskets, if your pool pump is below water level you will need to close the valves in front of the pump and set the multiport valve on the filter to ‘closed’.

How do you reset a Zodiac Tri chlorinator?

Press and hold the MINUTE button until the hours for the power pack and the cell are displayed. Press the HOUR button once to reset the hours for the cell.

How long does a salt chlorinator cell last?

This is all possible thanks to your pool’s salt chlorine generator cell. With proper care, a cell will last about five years. Eventually, though, it will need to be replaced.

Article first time published on

What should my chlorinator read?

On a Hayward Salt Chlorinator, your salt reading should be between 2,700 – 3,400 PPM (parts per million) with the optimum level of 3,200 PPM.

How many hours a day should a salt water pool pump run?

The average pool system needs to run anywhere between 4-10 hours so you will have to gauge it yourself though testing over time.

Is it OK to run pool pump 24 hours a day?

The size of your pool, the efficiency of your pump and filter, and how dirty your pool is are just some of the factors you need to consider. Nevertheless, most pool cleaning professionals would advise against running a pool pump for more than 8 hours a day.

How do you know if salt chlorinator is not working?

The easiest way to ascertain if the chlorinator is working is to make sure the cell is clean by checking the needle or production lights. Ensure there is enough salt in the pool. On the chlorinator box there should be a light or dial that indicates it is working.

Why are my chlorine tablets not dissolving?

If the tablets are not dissolving, and you get a strong smell of chlorine when you open the chlorinator, you probably have a bad check valve in the chlorinator. It is not allowing any water to move through the chlorinator, and any water that is there simply sits there and builds up a yellowish chlorine gas.

How do I reset my Hayward Aqua Plus?

Turn the filter pump on. You must reset the system by entering the ‘Diagnostic Menu’ and then hitting the right arrow key once and then pushing the plus key once. This should reset the light and message.

How do you calibrate a Jandy salt cell?

Press and hold the ‘Pool Temperature’ (‘D’) key for 15 seconds. The system will beep when the button is pushed, it will beep again after 10 seconds, and again after 15 seconds. Release the key after the third beep. Press ‘Salinity’ (‘C’) key within 5 seconds to enter temperature change screen.

How do you test a Hayward Salt Cell?

Turn off the power to the system and deactivate the pool pump before removing the Turbo Cell. Remove the Turbo Cell. Once removed, look through the cell and inspect for scale formation (light colored crusty or flaky deposits) on the plates and for debris that is caught on the plates.

How do I reset my Hayward OmniLogic?

Shut Down – When Shut Down is selected, the OmniLogic will turn off all pool equipment and report when it is safe to remove power. When this message is displayed, you can either power off the unit or restart the OmniLogic by touching the large power button displayed on the left side of the screen.

What happens if salt level is too high in pool?

Having too much salt in your pool water can result in unnecessarily increasing chemical expenses. But having too little salinity restricts the amount of chlorine being generated and can lead to algae and bacteria growth.

How do I know if I need a new salt cell?

• Looking worse for wear, it’s lost a few plates and the acid baths just aren’t working.
• Your pool is starting to turn green or cloudy, even though your chlorinator is turned up to 100%.

How do I check my cell hours on my Zodiac Tri chlorinator?

Press and hold the SELECT button for about 15 seconds, until you see a second menu appear. Scroll down to OPERATING HOURS. You will see that your cell hours are at 6000 hours or above. Press SELECT.

How do I reset my Hayward salt cell after cleaning?

If the Inspect Cell Light is the only LED light flashing, then you can reset it by simply holding down the diagnostic button for 3 seconds, then release. The Inspect Cell indicator will now reset and will later come back on after another 500 hours of use.
