The best prevention is to allow ventilation by spreading a healthy layer of coarse gravel over a plastic membrane that allows the rain water to run away and then dry. Skirting the lower sections of the deck also enables moisture to be trapped under the deck. Tops dry, bottoms don’t = Cupping.

How do I keep my deck boards from shrinking?

You can use a framing nail or a 16D nail to make sure that each board is a uniform distance from each other. However, if you’re building with wet lumber, you should leave boards 1/16” apart, as this lumber will shrink more over time.

Should deck boards be bark side up or down?

“Bark side down” orients the board so the end grain growth rings curve upward. This creates a crowning warp when wet. As a result, water is shed from the board, as opposed to pooling on it. Also, the exposed board face is heartwood (closer to the tree’s center) versus sapwood, and heartwood is more decay-resistant.

How do you keep timber from cupping?

Cupping: any cupping is temporary and can be corrected by wrapping the timber panel in plastic and then storing it on a flat, dry surface away from any wind, rain or direct heat. To avoid future cupping problems, the timber needs to be envelope-sealed (top, bottom and sides) with at least two coats of sealant coating.

What is the proper gap between deck boards?

Proper wood deck board spacing should have at least a 1/8 inch gap after the decking has dried out. If you install your wood or treated deck boards while they are still wet boards, then they should be attached without a gap between them.

Does pressure treated wood shrink as it dries?

Even products that are sealed and treated are going to shrink. This most typically occurs across the width of boards, so builders should take into consideration the fact that their lumber will shrink over time. Additionally, as part of the drying stage of treated wood, the boards will crack, also referred to as checks.

Why are my deck boards shrinking?

The simple science is that wood is made up of fibers. And these fibers have the ability to hold on to moisture. When these fibers hold moisture, they tend to expand, making the boards bigger. And when they dry out, the fibers contract, making the deck boards shrink.

How do you fill space between deck boards?

While you might be tempted to fill in gaps in your decking with wood filler or caulk, the natural movement of the boards can eventually cause the materials to break loose and make the gaps even worse. However, you can use rope to easily fill the gaps.

Are nails or screws better for decking?

Nails have one huge advantage over screws when building a deck – they bend. Decks are often subject to the force of heavy winds. Due to the way wind can get beneath a deck and pull on it, nails will bend and prevent the deck from moving while screws, which have a significantly lower shear strength, will break.

What is a breaker board on a deck?

To keep the deck looking good over time, deck professionals use breaker boards. These boards run perpendicular to the deck surface. Breaker boards are used to control expansion by keeping decking the same length. … For other options, the decking gap is the gap between decking and the breaker board itself.

Article first time published on

How do you fix cupped wood panels?

The process is simple. Put the dry side down on a flat surface, one that restricts air movement across the bottom of the wood. The wide board or panel will be sitting like a rainbow, with the two legs down and the center up. Then just proceed to dry the top side, either with the sun or a hair dryer.

Does sealing wood prevent expansion?

Sealing wood will not prevent it from warping or expanding. Sealing both ends of the wooden plank may help prevent the ends from expanding or shrinking faster and exacerbating the warping of the plank. However, there is no guarantee treating wood with a wood sealer will prevent it from warping or expanding.

What is cupping in timber defect?

Shrinkage Defects Cup – ‘cupping’ is a hollowing of the board throughout its length on its Bark side face: it is for this reason that solid timber window sills, for example, should be positioned ‘heart side up’ (i.e. to ensure condensate does not collect in the middle of the sill).

Should deck boards be parallel to the house?

Decking running parallel to the house makes the deck look wider and blends the deck into the house. If the decking runs perpendicular, the deck looks long and extending far out, away from the house.

Can you sand cupped deck boards?

If the cupping is shallow use a plane or belt sander to take down the high edges. If it’s pronounced, either pull the nails and reinstall the board upside down, or replace it.

Can you use decking boards upside down?

It is entirely up to you whether you lay the boards grooved side up or down but, there are a few things you should bear in mind. Deck boards with grooves are designed to channel water away from the deck. To help with drainage, they should be fitted with a slight tilt in the direction of the grooves.

Should deck joists be 2x6 or 2x8?

For upper-level decks, 2×10 is recommended as the minimum size to use for strong guard post connections. 2×6 joists should only be used on ground-level decks that do not require, and will not provide for, any guards. … Most decking is not strong enough to support longer spans than 16″.

Can you put deck boards tight together?

Rot – Deck boards that are spaced too tightly together are more likely to trap dirt, debris and moisture, which is the perfect mixture for making rot. Water Drainage – Adequate gaps are needed for water drainage. Without it rot is more likely, mold can build up easily and slick boards can become hazardous.

Does pressure treated wood shrink or expand?

Over time, most treated lumber will shrink slightly across its width as it dries out. Take this small amount of shrinkage into account when laying decking or fence boards. After being outdoors for six to 12 months, treated lumber will develop cracks, called “checks,” along the surface of each board.

Will deck boards shrink or expand?

Any type of decking board will expand and shrink, whether it’s wood, plastic, or composites. … However, they don’t change in size as much as wood or plastic. Wood fibres hold the shape when the composite undergoes thermal expansion, while the plastic fibres do the same when moisture is involved.

Does pressure treated deck boards shrink?

Regular pressure treated wood tends to be somewhat wet when it’s new. That means, as it weathers in the sun and the heat, it will dry out some and shrink slightly. … In this case, some space between the boards is a good idea because the wood can actually expand slightly over time.

What is the fastest way to dry pressure treated wood?

How to Speed up Drying of Pressure Treated Wood. The fastest way to dry treated wood is by having it kiln dried by the manufacturer. This takes one to eight weeks. You can also lay the treated wood flat and stack them in a crisscross pattern to air-dry for 2-3 days.

Should I sand pressure treated wood?

Sanding pressure-treated wood is actually contraindicated because, as Sand & Stain warns, you’ll end up partially removing the protective coating created by the pressure treatment, and the wood will look terrible.

Should deck boards be butted together?

We recommend butting treated deck boards together because as the moisture dries from the wood, the boards will shrink and naturally form gaps to allow water drainage. (Depending on moisture content, cedar, cypress and especially hardwood decking may require deliberate spacing for consistent joint sizes.)

Do you countersink deck screws?

Conclusion: Deck Screws Should Be Counter Sunk Never Flush Installing deck screws slightly below the surface accommodate the shrinking of the decking as the boards dry.

Do you need to pre drill for deck screws?

Deck screws installed in the field, not close to the board’s end or edge, need not be predrilled. Predrilling is required near the end of deck boards to make room for the screw. As the screw is acting like a wedge, driving between the wood fibres. That screw pushes against the decking, splitting open the board.

Can you fill cracks in pressure treated wood?

You can use a great waterproof wood epoxy to fill large cracks. It’s stainable and while it won’t look exactly like the natural wood, you’ll stop water from doing more damage once you seal the wood and coat the epoxy. Any others that have large splinters or delamination will have to be replaced.

Can you use caulk on a deck?

Once the wood is dry, fill any gouges, holes, and cracks deeper or wider than ¼ inch with a paintable acrylic caulk. Use a putty knife to scrape off the excess, then allow the caulk to set until it skins over, probably 30 minutes.

Can you cut Ekodeck?

For best results, use carbide tipped blades. When using a drop saw we recommend a 60-80 tooth blade for cutting.

How do you flatten cupped glue?

Place it on several 1″-thick scraps and let it stabilize for a few days. Then finish it and install on the chest. If that doesn’t remove the cup, you can save thickness by ripping the top into narrower pieces, flattening them, and rejointing the edges. Then glue the top back together.

What causes wood to cup?

Cupping is caused when wood planks expand due to heat and/or moisture. That causes the planks to push up against each other. Much like the formation of mountains and valleys, the two pieces pushing against each other causes the edges to rise upward and the middle of each plank to sink. That is cupping.
