1) Calculate the weld area (cross section of the weld) including root and cap reinforcement in square millimetres. 2) Multiply weld area by pipe circumference (weld length) to give a weld volume in cubic millimetres. 3) Divide this answer by 1,000,000,000 to give weld volume in cubic metres.

How do you calculate welding?

1. Multiply the size of weld and weld strength.
2. Divide the maximum permissible tensile stress by the above product.
3. Multiply the resultant by 0.707 to obtain the length of the weld joint.

How is weld strength calculated?

1. σt is the tensile strength of the weld (determined by the filler metal being used) in PSI.
2. F is the force the weld can handle, in other words, the strength of the weld in lbf.
3. A is the effective area of the weld.
4. Throat = “w” x cos 45˚ = (1/4) x (0.707) = 0.177”

What does the 60 mean in a e6011 welding rod?

The “60” in 6011 lets you know that the final weld will have a strength of sixty thousand pounds. The third digit tells the positions the rod can be used in. “1” is for all position rods. You can weld horizontal or vertical with 6011. (A rod with a “2” in the third position is only suitable for flat welds.)

How many welding rods are in a box?

BrandVin ARCSize1 mmMaterialMild SteelLength450 mmPieces Per Box90 Pieces

What is weld size?

For fillet weld, the weld size is the distance from the root to its toe and weld throat is the minimum distance from the root of the weld to the face of the weld. For groove weld, the weld size is the width of the weld coverage and weld throat is the depth of the groove filled with weld.

How strong is a 6mm fillet weld?

To give you some idea, a “standard” 6 mm fillet weld has a capacity of 1kN/mm.

What is the difference between 6011 and 6013 welding rod?

The 6013 electrode is best used for light to medium penetration on a thin metal, or sheet metal. The 6011 electrode offers more penetration than the 6013 so you can weld a slightly thicker material.

What is the strength of weld per mm?

What is the strength of weld per mm length used to connect two plates of 10mm thickness using a lap joint? Strength of weld = te [fu/(√3 x 1.25)] = 410 x 4.2 /(√3 x 1.25) = 795.36 N/mm.

What does the 8 in 7018 mean?

In welding 7018 70 stands for 70 ton tensile strength of the material 1 stands for type of weld and 8 stands for position of weld. 348 views Answer requested by.

Article first time published on

What is a 7010 welding rod?

A high cellulose electrode for welding Carbon- 1/2 Moly piping used in high pressure, high temperature steam service. Inweld 7010-A1 may be used in any position, but is best suited for vertical-up or vertical-down welding. Exhibits a forceful arc with deep penetration and a fast-freeze weld puddle.

What is a full strength weld?

Full strength on a fillet weld is a leg length equal to at least 3/4 of the of the thickness of the thinnest plate being welded. In a perfect world full strength may equal gas tight, in reality it means no such thing. Gas tight means that the weld is good enough to be pressurized to some predetermined pressure.

How many kg of welding rods are in a box?

1 box Wipweld 6011 Welding Electrode Rod 5/32 (20 kg) | Shopee Philippines.

How do you read welding electrode codes?

1. The letter “E” indicates an electrode.
2. The first two digits represent the resulting weld’s minimum tensile strength, measured in pounds per square inch (psi). …
3. The third digit represents the welding position(s) for which the electrode can be used.

How heavy is a welding rod?

Item Number89608Scanner Description6011 Welding Rod 1/8Inventory StatusIn StockWeight10.79 lbBrandAPPROVED SUPPLIER

How many passes is a 3/8 fillet weld?

so by this theory 3/8″ is two/three pass, 1/2″ is a 4 pass e.t.c. If the fillet weld ends up larger than 1/2″ then I would normally use a butt weld instead as it is usually cheaper.

Is a weld stronger than the metal?

In most normal steel applications, the filler metal composition varies slightly from that of the base material which results in higher as welded strength. When these steels are welded, as solidified metal it is harder and stronger than the surrounding base metal.

What is a root face in welding?

The measurements of the portion of the groove face within the joint root.

How do you measure weld size?

Fillet welds may have a size associated with them. This size is called out on the left side of the symbol before the vertical side. The size is indicating the leg length of the weld. If a single size is called out this is specifying that weld should have equal leg sizes.

How is weld width calculated?

The width of the weld cap, w, is given by W = 2(tan b x t) + g. The area of the excess weld metal is approximated by the formula (W x h)/2. The area provided by the root gap by g x t.

How thick should a weld be?

Welds ideally should be 1.5 times the thickness of the material being welded. So if you are welding two pieces of 1/4″ steel together then the weld would be . 25 x 1.5 = . 375 or 3/8″ of an inch.

How do you calculate minimum welding?

The size of fillet weld height approximately specifies the = 0.7 formula, where z is the fillet weld width. Minimum fillet weld height is selected according to the thickness of the thicker welded part and according to the material.

How do you strengthen welded joints?

Fillet welded joints may be treated with a variety of techniques to increase the fatigue strength with respect to failure at the weld toe. The most common technique is weld toe grinding, preferably with a grinding burr rather than a disc.

What is the minimum size of effective throat thickness?

Explanation: Effective throat thickness is the shortest distance from the root of fillet weld to face of diagrammatic weld(line joining the toes). The effective throat thickness should not be less than 3mm and it should not exceed 0.7t or 1t, where t is thickness of thinner plate of elements being welded.

What welding rod is stronger 6011 or 6013?

The 6013 has a more mild penetration with a larger pool that doesn’t cut through rust like the 6010 or 6011. This electrode is a favorite for structural welders based on its smooth arc. Its mild penetration and bigger pool leave larger, stronger, less defined beads.

What is a good all purpose welding rod?

Top 5 All-Around Welding Rods. Best Overall: Hobart 770458 6011 Stick. Best Vertical Welding Rod: Forney 31105 E6011. Best for Experienced Welders: Forney 30705 E7018. Best 6013 Welding Rod: Forney 303305 E 6013.

What is 6010 welding rod used for?

Usually, both electrodes are used together in various industrial applications (pipelines welding, storage tanks, etc.). E 6010 is used for welding the joint root-pass for proper penetration, and E 7018 is used for the hot-pass, fill-up, and cap beads.

Do you Weld 7018 AC or DC?

The 7018 welding rods are used for pipe welding and structural steel welding and repair welding. This low-hydrogen, usually DC, all-position electrode can also be used with AC, which not many welders may know. The 7018 provides a good bead appearance and smooth, strong welds. It also works on higher strength steels.

What does the 1 stand for in 7018?

The 7018 Welding Rod The “E” in E7018 electrode indicates a tool used for an arc-welding process. The 70 means it makes welds that are very strong (70,000 psi). The 18 means two things: The “1” means the electrode can be used in any position, and the “18” means low hydrogen and usually DC current.

What amp do I need to weld with a 7018 Rod?

Amperage Rule In general, the 7018 rod is used with currents up to 225 amps. A rule of thumb is to use 30 amps of current per 1/32 inch of rod diameter. That would mean using 90 amps of current on a rod that is 3/32-inch in diameter.

What is 8010 welding rod used for?

An 8010 welding rod is specifically used for vertical down welding and out-of-position welding techniques for steel pipes up to 80 Ksi tensile strength, although it can be employed in all welding positions if desired.
