The primary benefit winder staircase has over having a flat landing is its space-saving abilities. A straight staircase, for example, which is 3 feet wide and 18 feet high, fills around 105 sq feet of your space, while a winder staircase of same proportions fills 45 sq feet of space only.

How much space do you need for a winder staircase?

The primary benefit winder staircase has over having a flat landing is its space-saving abilities. A straight staircase, for example, which is 3 feet wide and 18 feet high, fills around 105 sq feet of your space, while a winder staircase of same proportions fills 45 sq feet of space only.

Do winder stairs save space?

Advantages of Winder Stairs: The main advantage of winder stairs is that they require less space than many other types of stairs. They are very common in older homes and often used as a secondary staircase.

Are winder stairs legal?

Winder stairs are permitted in the building code as of 2019. The code says the minimum tread width on the inside radius needs to be 6 inches. It also says that the tread depth at walk line of the stairs measured 12 inches in from the inside tread edge must be no less than 10 inches.

What are spiral stairs called?

Winders. Winders are steps that are narrower on one side than the other. … A series of winders form a circular or spiral stairway. When three steps are used to turn a 90° corner, the middle step is called a kite winder as a kite-shaped quadrilateral.

What are the dimensions of a spiral staircase?

Spiral staircases generally range in size from 42″ to 76″ in diameter. The floor opening at the top of the staircase must be two-square-inches bigger than the staircase’s diameter. Spiral staircases are also measured by their floor to floor height, footprint, walking space, and landing length.

How much space does a spiral staircase take?

A spiral staircase will save you space, with a typical 44” by 44” footprint that allows for the stairs themselves, the railing, and additional space for a hand holding the railing. By comparison, a traditional staircase requires an 88” by 36” footprint on the bottom level and a 48” x 36” footprint on the top level.

What is a kite winder staircase?

Kite Winder Stairs Kite Winder are stairs with a straight flight and steps which turn at the bottom. The name kite coming from the ‘kite’ shaped step which is formed a the steps turn.

What is a double winder staircase?

A common feature which is often required when designing the configuration and installation of a new staircase is a winder. A double winder allows a staircase to undergo a half (180 degree) turn without the need for a landing by narrowing one side of the treads and one or more winders may be required.

What is a kite winder?

(ˈwaindər) a triangular winder on a staircase.

Article first time published on

How big does a landing have to be UK?

5) Landings; Part of the floor, the area at the bottom or top of the stairs. The building regulations state that, the width and length of a landing which constitutes part of the floor area must be at least equal to the smallest width of the narrowest flight of the staircase.

Do spiral staircases take up less space?

Spiral Staircases do take up less space than conventional staircases. This is because the steps are all located within the diameter of the spiral, regardless of the height.

Is there a ladder that can be used on stairs?

There’s nothing to build. You can use it with most light- or medium-duty single and extension ladders. There’s nothing to install, so you can pick whichever ladder is right for the job at hand, and if you don’t need it, it’s out of the way.

What is the railing at the top of the stairs called?

Handrail: what is a handrail? A handrail, also called a bannister, is what people hold onto for support when going up and down the staircase. The handrail is fixed to vertical posts (balusters) or a wall up one or both sides of the staircase.

How much space does a spiral staircase require UK?

All building regulation spirals must comply with the 100mm sphere rule, i.e there must be no gaps greater than 99mm anywhere on the spiral staircase.

What is the minimum diameter for a spiral staircase?

Spiral stair building code requires your stair to have at least a 5′ diameter. Our 5′, 5’6” and 6′ code package stairs will meet code in many states across the nation.

How do you calculate spiral staircase dimensions and designs?

1. Floor height ‘h’ = 2700mm.
2. Riser ‘r’ = 225.
3. No of risers =2700/225 = 12.
4. No: of Steps = 11 + 1 landing platform.

What is half landing staircase?

A half landing staircase gives the user a flat platform that is situated midway up the staircase, allowing the stairs to undergo a half (180°) turn, allowing it to ascend to a point that is better situated in the home, whether this is through preference or necessity. …

What is helicoidal staircase?

A helical staircase is simply a formal name for a curved staircase. It comes from the famous and highly distinctive structure of a double helix, the shape of a DNA molecule, in which two strands twist around each other.

What is a double kite staircase?

A double-kite stair case is a stair case that turns twice.

What are the types of staircase?

• Straight Staircase. Literally, as its name, it has no bends. …
• Straight Stairs with a Central Landing. …
• L Shaped Staircase. …
• U Shaped Staircase. …
• Spiral Staircase. …
• Curved Staircase. …
• Bifurcated Staircase. …
• Ladder Staircase.

Is it illegal not to have a banister on stairs?

Handrails are mandatory. Stairs should have a handrail on at least one side if they are less than one metre wide, and on both sides if wider than this. Handrails should be placed between 900mm and 1000mm above the highest point on the staircase steps.

Are spiral staircases legal UK?

Part K of the Building Regulations provides the guidelines for ensuring occupants or visitors to a house are protected against falling, collision or impact. All the spiral and helical staircases that we manufacture at Spiral UK are compliant with British Standards Document BS 5395 Part II.

Do you have to have a landing at the top of stairs?

There shall be a floor or landing at the top and bottom of each stairway. Exception: A floor or landing is not required at the top of an interior flight of stairs, including stairs in an enclosed garage, provided a door does not swing over the stairs.

What is an alternating tread device?

The IBC defines an ALTERNATING TREAD DEVICE as a device that has a series of steps between 50 and 70 degrees from horizontal… in an alternating manner so that the user does not have both feet on the same level at the same time.
