The nails should provide a minimum of 40mm penetration into the rafter, so a nail length of 65mm is generally recommended. Start at the lower edge of the roof, nailing the batten into place at the centre of the rafter. Joints should be directly over rafters, with the batten square cut, tightly butted and skewed nailed.

How do you attach battens to rafters?

The nails should provide a minimum of 40mm penetration into the rafter, so a nail length of 65mm is generally recommended. Start at the lower edge of the roof, nailing the batten into place at the centre of the rafter. Joints should be directly over rafters, with the batten square cut, tightly butted and skewed nailed.

Should you screw or nail roof battens?

Fixing timber battens to timber supports: Use the appropriate fasteners. This is extremely important because using the wrong fasteners may lead to roof failure. For example it might appear that using 75mm nails to attach a 35mm batten to a rafter would be sufficient.

Where are battens installed on a roof?

Roof battens are thin strips of material that may be made of wood, plastic or metal. They’re installed before the tile is laid on the roof and may serve more than one purpose.

How do you secure battens?

The battens should butt tightly against the top trim board and be flush at the bottom with the wider vertical boards. While the width of the battens is your choice, they should be wide enough to overlap the edges of the larger boards by at least ½ inch on both sides. Caulk, then paint or seal the siding.

How long do roof battens last?

How durable are battens? Most battens are supplied with an industrially applied treatment process designed to provide a 60-year design life under Use Class 2. The relevant Standard is BS 8417:2011 Preservation of Wood.

What is the difference between purlins and battens?

But a “purlin” is applied directly onto the roof rafters, running perpendicular between them, while a “batten” is nailed to roof sheathing or applied over an existing roof for installation of a new roof.

What is a Perling?

A purlin (or historically purline, purloyne, purling, perling) is a longitudinal, horizontal, structural member in a roof. In traditional timber framing there are three basic types of purlin: purlin plate, principal purlin, and common purlin.

Should roof battens be treated?

Treatment – Roofing battens should be preservative treated to Use Class 2 in accordance with BS 8417. Different manufacturers use their own types of preservative treatment and may offer different guarantees as a result.

Are battens necessary?

You do not have to use a batten roofing system under most building codes. In some cases, it is necessary, but in most cases using batten on your roof is a choice to gain the benefits of using this system. There are primarily two options for roofing, a direct to deck system or a roof batten system.

Article first time published on

Which way do battens go?

Make sure the battens are inserted with the tapered (thin) end towards the luff and the stiffer (thick) end towards the leech.

What is a roofing batten?

Battens are the lengths of wood that are laid in-between the rafters to secure the roofing felt and to accept the tiles or slates when they are fitted. … They are used to locate the roof covering in straight, consistent rows, and provide a strong anchor for the nails or clips used to secure the tiles or slates.

What are batten screws?

Batten Screws are heavy duty Screw, typically used for fixing larger timber joints such as decking sub-frames. These screws are also commonly used for laying larger decking and boardwalks etc.

How far apart should battens be?

Typically, batten are spaced anywhere from 12” to 24” apart. I think it looks best to space them as close to 18” as possible, but that’s just a personal preference.

Are roof battens structural?

The quick answer is YES. Roof battens no matter how you look at them are a structural element of any roof. Roof battens are one of those constantly misdiagnosed and overlooked aspects of roof construction. But roof battens provide some extremely important structural functions to protect your roof.

Do you caulk board batten?

For cement board and batten siding, installation requires the battens to be caulked.

What is the difference between board and batten and wainscoting?

Wainscoting is a protective barrier applied to the lower half or lower third of a room, usually on all the walls. Board and batten refers to a specific design that can be used to create this protective barrier.

How do I support my roof purlins?

Roof purlins are usually supported by 2×4 or 2×6 posts or struts. The posts will be spaced in four-foot distances for 2×4 purlins, while 2×6 purlins have them spaced at six feet apart. If the space between the posts is bigger than eight feet, a brace will be needed to avoid buckling.

What is difference between Rafter and batten?

Rafters – are supporting timbers that span between walls or other supports and carry the roof which ceiling battens or the ceiling itself can be attached to. You can see the rafters here on this image. Battens – are a length of squared timber or metal used to hold something in place or as fastening against a wall.

What is batten door?

Definition of batten door : a door made of usually narrow boards set lengthwise and secured by battens nailed crosswise.

Do you need to counter batten a roof?

Roof tiles are usually laid horizontally, attached to timber tiling battens. … If the layer of breathable membrane is draped across your roof pitch in such a way that it creates gaps between each rafter,it enables water to run out beneath the tiling battens – meaning that there is no need for counter battens.

Should I counter batten?

12 – Counter battens – If you’re using a vapour permeable (breathable) membrane with a close fitting roof covering, such as shingles, then it needs to be counter battened to allow ventilation of the batten space. The position of the first batten should be the batten gauge plus half the thickness of the batten.

Can you felt over battens?

The practice of lining roofs with a permanent sheet roofing underlay has become a universally accepted practice in the UK over the last fifty years and people are now asking: “Is roofing felt waterproof?” The sheeting or sarking felt, is laid over the supporting rafters or counter battens, and beneath the tile or slate …

What is timber batten?

A batten is generally a strip of timber (although it can also be steel or plastic) which is used in the construction of buildings. They are typically used as spacers to raise the surface of a material, or as a secondary framework onto which a surface may be fixed.

Can you felt and Batten in the rain?

IS FELT WATERPROOF? The answer is Yes felt is waterproof, the sarking felt which is laid over support rafters or counter battens, beneath the tile or slate battens provides waterproofing.

Is board and batten easy to install?

You can choose to replace all of your base molding when you install board and batten, but that isn’t very cheap or easy so I didn’t want to go that route. … That works well because then the board and batten is as narrow as the top of the base molding so there is no problem.

Do roof battens rot?

You can get some rot in roof battens, but, generally, it’s at the roof’s edges, such as at chimneys or in verges – the edge of a roof that has a gable. Battens in the main body of the roof do not rot, unless there are some major long-term defects, or the tiles have become porous.

Why are wood battens blue?

For fixing Roof Tiles, Slates, and sheets, Batten colour may vary. The battens are blue in colour indicating that each individual batten has been assessed, graded and complies with the strength requirements of BS 5534 : 2003 + A1 : 2010.

Why are some roof battens blue?

The reason our product is dyed blue is to distinguish it as meeting the necessary standard: it’s a colour commonly used by Nordic and Baltic suppliers. But it’s the BS5534 grading stamp, not the colour, that’s important.”

How do you attach purlins to rafters?

Lay the first purlin at the ridge of the roof down to the chalk line beginning at either corner. Fasten the purlin with 16d common nails into each vertical rafter. Insert two equally spaced nails into the rafter. The rafters are generally spaced every 16 inches on center.

Are purlins necessary?

Different purlins are used for different purposes, including structural support of walls or floors. Purlin is important because without it, there’s no frame for the sheeting on the roof to rest on, making purlins critical to the structure of the roof.
