Lay the cut flashing down at the corner over a shingle that is already in place. The corner cut should be facing upwards. Gently hammer the 45-degree cut around the corner of the porch/roof seam until it sits flat. Secure it to the house wall with a roofing nail at each corner.

How do you install flashing under existing siding?

Nail the siding, stopping before placing the final nail at the end. Slide half of the piece of pan flashing, oriented vertically, under the end of the siding. Make sure the bottom of the flashing does not emerge at the bottom of the lap siding. Secure the flashing and the siding by fastening them to the structure.

How do you flash a porch roof to a house?

Lay the cut flashing down at the corner over a shingle that is already in place. The corner cut should be facing upwards. Gently hammer the 45-degree cut around the corner of the porch/roof seam until it sits flat. Secure it to the house wall with a roofing nail at each corner.

How do I put flashing on my porch roof?

Install the Flashing Place the flashing between the joint of the house and the roof. The flashing on the wall should be flush against it, and the porch roof portion should be on top of the shingles. Nail the flashing securely in place using roofing nails. Try to keep the nails as flush as possible to the edges.

What can I use to seal flashing?

Renew flashing seals by chipping out the old mortar and caulking along the edges of the flashing. Use special masonry caulk to seal the joints between the flashing and the chimney. Seal the seam between the cap and step flashing with urethane roofing cement or silicone caulking compound, as shown at right.

Does roof flashing go under siding?

In certain instances flashing may need to be installed on the exterior of siding. However, in most instances, step flashing should be installed “behind” siding. It is always recommended to install step flashing behind stucco, Dryvit, wood panel, lap siding, vinyl siding, cedar shingle siding, etc.

What should I put between wood and concrete?

Anyplace where wood meets the ground or concrete, the lumber must be pressure treated. For additional moisture protection, a gasket or strip of closed-cell foam can be installed between the concrete foundation and the sill plate.

How do you seal a porch roof?

1. Identify the location of the leak. …
2. Fill a caulking gun with a watertight polyurethane or oil-based sealant and hold it at an angle to insert the product directly into the gap. …
3. Apply the sealant in a smooth bead all the way along the gap. …
4. Check the joints of a corrugated metal or plastic roof.

Do you need flashing on a covered porch?

“Flashing is required where exterior porches, decks, or stairs attach to a wall or floor assembly of wood frame construction.

What are the different types of flashing?

• Continuous flashing: Also known as “apron flashing”. …
• Drip edges: Often installed under the roofing felt along the eaves of a roof. …
• Step flashing: Step flashing is a rectangular piece of flashing bent 90 degrees in the center. …
• Valley flashing: A W-shaped piece of metal flashing.

Article first time published on

Do you need to caulk roof flashing?

Roof flashings can be made from thin metal, rubber, and a few other materials. … It’s okay to use caulk and roofing cement as a last resort to make a temporary leak repair, but don’t allow a roofer to convince you they’ll work for the long term.

Does roof flashing need to be sealed?

As long as the flashing has been installed properly, you can repair a leaking seam using simple roofing cement in most instances. Simply push the seam back down and secure it in place with screws if necessary, and then apply roofing cement around all the edges of the flashing for a watertight seal.

Should you caulk flashing?

It is generally not a good idea to use caulking on wood siding. … Flashing acts as a waterproofing layer for this type of siding, and caulking will prevent the flashing from doing its job. As far as trim boards are concerned, you should not caulk around these areas if they sit on top of the surface of your siding.

How do you seal flashing brick to roof?

Use a good masonry sealer and spread it over the area where you are going to place the metal roof flashing. Use a regular paintbrush to apply the sealer to the brick. This sealer will help the adhesive stick to the mortar much better. Wait until the sealant becomes hard before you proceed to the next step.

Can you put wood directly on concrete?

Wood in direct contact with concrete, and the dampness often found there, will rapidly decay. To avoid this, use pressure-treated lumber. … This indicates that the wood contains a quarter of a pound of preservative per cubic foot, which is sufficient for use against exposed concrete, outdoors as well as in.

Can you attach wood directly to concrete?

The easiest approach is simply to nail the wood to the concrete. … These nails are driven through a board and into concrete underneath, much like nailing a wood board to a wood floor. These nails are cheap, hold well (as long as they penetrate at least ¾ inch into the concrete) and are extremely hard to pull out.

What is the difference between flashing and step flashing?

The base flashing (or apron flashing) is the bottom piece. … Step flashing: Step flashing is a rectangular piece of flashing bent 90 degrees in the center. It is used for roof to wall flashing. Multiple pieces of the flashing will be installed in layers with shingles to ensure the water flows away from the wall.

Can you install flashing over shingles?

Flashing should overlap the roof-covering material, but on asphalt shingle roofs, for aesthetic reasons, the part of the headwall flashing that extends down over asphalt shingles is often covered with a course of shingle tabs. … Wind-driven rain can enter at these gaps, causing roof leaks.

How do you install flashing after shingles?

In order to properly install new flashing, you’ll have to remove the shingles surrounding your old flashing, and then re-lay them after installation. Typically, flashing is installed using roofing nails and roofing cement.
