Setting the governor is accomplished by activating a solenoid at any speed less than normal over-speed, thus setting the grips and activating the safety. Resetting is accomplished by first running the car briefly in the “UP” direction. A spring resets the governor grips.

How do you adjust the governor on a 16 HP Briggs and Stratton engine?

To set the governor at its proper position, loosen the screw on the governor arm so the governor arm will turn on the governor shaft. Move the governor arm so that it stretches the spring as much as it can. Turn the slotted end of the governor shaft clock wise as far as it will go.

What does the governor do on a Briggs and Stratton engine?

The governor system is like a cruise control system. It maintains the speed of your lawn mower or outdoor power products. When Briggs & Stratton governors are adjusted properly, they keep your speed steady regardless of engine load – the amount of work the engine must perform.

How do I adjust the throttle on my Briggs and Stratton?

Adjust the throttle lever to the “Fast” or “High” setting. Loosen the screw that holds the mounting bracket that supports the cable with a flat-head screwdriver. Loosen it just enough to allow the cable to move through the support freely.

How do you know if governor is bad?

Easy to tell if the Governor is Toast. Run the engine at 3/4 throttle, and see if the governor arm is applying pressure by manually pushing the arm away from the carb. No Pressure=Bad Governor. Otherwise, You should be able to get it working correctly by adjusting the governor and the Throttle Screw.

How do you adjust the governor spring on a lawn mower?

To adjust the governor, you would loosen the screw on the bottom of the governor arm and push the governor arm so the throttle is wide open. Then you would turn the bottom “clip” (which is connected to the governor shaft) counter clockwise. This will set the governor shaft on top of the governor spool.

What makes a Briggs and Stratton engine surge?

The most common reason for a surging lawn mower engine is a blockage in the fuel supply, but there are other possibilities: Bad gas. Bad spark plug. Dirty / faulty carburetor.

What causes lawn mower to rev up and down?

A lawnmower that hunts and surges may be experiencing something as simple as an airflow issue. If the air that the engine requires to run is blocked, especially sporadically, it can cause the engine to slow down. When the blockage moves or clears, the engine may suddenly rev up in response.

How can I speed up my lawn mower engine?

1. Remove the flywheel housing from the top of your engine. …
2. Unscrew the bolt holding the governor flap next to the flywheel with the proper sized wrench. …
3. Inspect the muffler. …
4. Fill the gas tank on your mower with a high octane gas. …
5. Maximize the air flow.

How does a governor control speed?

A typical governor regulates an engine’s speed by varying the rate at which fuel is furnished to it. … If the load on the engine decreases, the speed will increase, the balls M will move out, and the member C will slide up the vertical spindle and reduce the steam admitted to the engine, thus reducing the speed.

Article first time published on

What item is set to adjust the engine idle speed?

The curb idle is set with the idle speed adjustment screw on the primary throttle linkage on the driver side of the carburetor.

What holds the throttle shaft in the idle position?

What holds the throttle shaft in the idle position? … The governor spring is directly connected to the throttle plate.

How do you adjust the governor on a generator?

Insert a flat screwdriver into the yellow governor control screw with a spring around the screw threads. This screw is located on the governor linkage. Monitor the tachometer reading during adjustment. Turn the screw counterclockwise to increase engine RPM, and clockwise to reduce engine RPM.

How does a transmission governor work?

The governor uses centrifugal force to direct oil from the oil pump through the shift valves to the appropriate clutches and brake bands. As you accelerate, the shift valves move out directing the oil through the valve body to the gear shifting mechanisms in the transmission.

What causes a lawn mower engine to lope?

Problems in the Fuel System The cap on your mower’s gas tank is vented with a small hole. … Surging is also caused by water that got into the fuel. A mower left in a heavy rain or condensation on a hot summer day can choke the engine. Empty the gas tank, properly dispose of the old fuel and try a fresh batch of gasoline.
