The easiest way to ascertain if the chlorinator is working is to make sure the cell is clean by checking the needle or production lights. Ensure there is enough salt in the pool. On the chlorinator box there should be a light or dial that indicates it is working.

How do I know if my saltwater cell is working?

The easiest way to ascertain if the chlorinator is working is to make sure the cell is clean by checking the needle or production lights. Ensure there is enough salt in the pool. On the chlorinator box there should be a light or dial that indicates it is working.

Why is my salt chlorinator not producing chlorine?

The saltwater chlorinator needs a sufficient flow of water for effective operation. A dirty skimmer basket, clogged or dirty filter, and a clogged pump strainer, can cause insufficient water flow for the chlorinator to produce less chlorine.

How do you know if a salt water cell is bad?

1. The power center displays a Check Salt message. …
2. The Cell Warning light displays consistently, shutting off for only a short while after cleaning.
3. Voltage is higher than normal.
4. Amperage is irregular (it should normally be zero or just slightly above)

How do I know if my Hayward salt cell is bad?

1. Looking worse for wear, it’s lost a few plates and the acid baths just aren’t working.
2. Your pool is starting to turn green or cloudy, even though your chlorinator is turned up to 100%.

Can a salt cell be repaired?

Salt chlorine generators require some maintenance and repair. … Chances are at some point you will face an expensive repair to your salt system, either a new salt cell, or a new control board. Both of these repairs can approach half the cost of a new system.

How long do salt generator cells last?

This is all possible thanks to your pool’s salt chlorine generator cell. With proper care, a cell will last about five years. Eventually, though, it will need to be replaced.

Can you clean a salt cell with vinegar?

As a thumb rule, go for a mild solution with a perfect blend of water and vinegar. Soak the saltwater cell or hot tubs (as the case may be) in a container with vinegar solution for a night. The solution can remove all sorts of remaining debris within a fortnight.

How do you calibrate a Hayward salt Cell?

Turn Salt System Off and On With the pump running, take the power switch down to the “Off” position, and then back up to “Auto”. You should hear a click within 10 or 15 seconds. When you do, press the diagnostic button five times in a row. The system will go through a recalibration process.

How often should I clean my salt cell?

How often should my salt cell be cleaned? Clean salt cells when scale develops on the metallic (titanium) grids, or once per season at the very least. Too frequent cleaning will erode the coating on the grids, which is what makes them work.

Article first time published on

What inspect cell means?

If both the “check salt” and the “inspect cell” lights stay on, it most likely means that no chlorine is being produced at this time and your salt level fell below 2300 ppm. Both lights will also stay on if the controller is set to the wrong turbo cell type, or if the cell is unplugged.

How much does it cost to replace a salt cell?

A well-maintained salt chlorine generator will last 3–7 years. Replacing the salt cell costs $700–$1100. Replacing the control board costs $500–$900. You can extend the lifespans by maintaining a consistent salt level, cleaning the cell only when needed, and using the reverse polarity function.

How do I know if my flow switch is bad?

”No Flow” light coming on probably means the cell’s flow switch has gone bad. Verify that the pump is running first (water is actually flowing through the line). If “No Flow” stays on the flow switch needs replacing. ”Flow” LED turning from green to red means water flow through the system has been disrupted.

How do you test an IntelliChlor salt cell?

Submerge the salt cell in a bucket of pool water, but do not get the wiring connections wet. Turn on the pump and activate the salt system. Put the output on the salt system at 100% for this test. Put the output back to the original setting when you are done.

What should my salt generator be set at?

We suggest you start your salt chlorine generator at 50 percent output and run it for a couple of days, then check the chlorine level. In a balanced pool, a good chlorine level is 1-3 parts per million. If your chlorine levels are low, you can raise the percentage, and if it’s high you can lower the percentage.

What is the best salt water chlorinator on the market?

1. Pentair 520555 IntelliChlor Salt Chlorine Generator – Best Overall. …
2. NeXa Chlor Pool Salt Chlorine Generator – Best Value. …
3. Hayward W3AQR15 Electronic Salt Chlorination System – Premium Choice. …
4. Solaxx CLG10A Saltron Retro Self Cleaning Salt Chlorine Generator.

How do you calibrate a Pentair salt Cell?

1. If the Intellichlor has been in operation for a few weeks, remove and acid clean the salt cell before field recalibrating. …
2. Manually test the salt level with salt test strips or an electronic salt tester.

How do I reset my Aqua Trol salt generator?

To reset, turn the unit to Off and then back to Auto. Wait for the relay to click (5 to 10 seconds). Desired Output % Dial 1 to 100% sets the level of cell operation in % of operating time.. Example: 50% (factory default) cell is operating and generating chlorine 50% of the total pump/filter operating time.

What do you do with muriatic acid after salt cell cleaning?

If clean, rinse with hose and reinstall. If there are still deposits after soaking, repeat the soaking procedure until clean. The water/muriatic acid mixture can be stored for later use or it can be disposed of. Follow the chemical manufacturer’s recommendations when storing or disposing the water/acid solution.

How often should you clean a Jandy salt cell?

The Jandy AquaPure Purification System makes chlorine for your pool out of salt, sanitizing pool water by killing algae and bacteria. If you discover the cell has scaling after checking once every two months, it must be cleaned.

What causes calcium buildup on salt cell?

What causes scale buildup in a salt cell? The salt cell’s ECG can provide a perfect breeding ground for two reasons: heat and high pH production. Heat — The hotter the water, the more calcium tends to drop out of pool chemical solutions and mineralize into a deposit.

How do I reset my Hayward salt Cell?

To reset, move the switch to ‘Off’ and then back to ‘Auto’. Wait for the relay to click (5 to 10 seconds). When the instant salt level is stable (and the negative sign still present), slide switch to ‘Super Chlorinate’ and back to ‘Auto’. It takes about 30 seconds for the unit to settle back on the default reading.

How do I reset my Hayward salt cell after cleaning?

If the Inspect Cell Light is the only LED light flashing, then you can reset it by simply holding down the diagnostic button for 3 seconds, then release. The Inspect Cell indicator will now reset and will later come back on after another 500 hours of use.

How do you clean a saltwater cell?

1. Turn off pool pump.
2. Remove the salt cell from the lines/unit.
3. Rinse the plates with a garden hose.
4. If you have a Zodiac LM Series salt cell, pour salt cell cleaner into the cell until the plates are covered. Let soak for 15 minutes.

Why do salt cells go bad?

Salt cells fail for a few different reasons, the main reason being lack of proper maintenance. It is very important to check the cell regularly for excessive buildup. … Use a cleaning kit designed for salt cells to keep the plates clear of buildup. Another common cause of salt cell failure is improper water balance.

How do you dispose of Salt Cell Cleaner?

This product and its container must be disposed of as hazardous waste. Do NOT dump into any sewers, on the ground or into any body of water.

How long should I run my salt chlorinator?

Run your system to run for 8-12 hours a day and set the chlorine output on the generator to 50%. After testing and determining the free chlorine readings over a few days, adjust the output on the generator only.
