For the type of clock with pendulum locking device at the bottom rear of the movement. To wind this clock, put the key on the square and turn counterclockwise, 1/2 turn at a time. Release the key gently after each half-turn, don’t let let it snap back suddenly.

Are kundo clocks still made?

Kundo is a trademark name of Kieninger & Obergfell, a long time German clock manufacturer. Key-wound 400 day clocks, such as this one, are no longer made. They were designed to be wound every 400 or so days, so owners typically wind them once every year on an anniversary date. The clocks are known for being reliable.

How does a rotating pendulum clock work?

The torsion pendulum rotates about the vertical axis of the wire, twisting it, instead of swinging like an ordinary pendulum. The force of the twisting torsion spring reverses the direction of rotation, so the torsion pendulum oscillates slowly, clockwise and counterclockwise.

Do you have to wind an anniversary clock?

As the name implies, the anniversary clock must be wound (at least) once each year. Many of these clocks will actually make it a whole year, but it is not uncommon for them to only last 8 or 9 months. The clock will probably begin to run slower as the year drags on. I recommend winding twice a year.

When were kundo clocks made?

There were torsion clocks produced before 1900 but in limited numbers from about 1894 onward but the real push was after 1900. The Kundo model you see here was made in the late 1950s or early 1960s, probably the peak and subsequent decline of the anniversary clock era.

Why does the pendulum on my clock keep stopping?

The reason a clock pendulum often stops swinging, after being moved, is because the clock case now leans at a slightly different angle then it did at its former location. … A clock is “in beat” when the tick and the tock are evenly spaced.

Who made kundo clocks?

The Kundo Anniversary 400 Day Clock, made by German manufacturer Kieninger & Obergfell, was originally produced in 1923. The word anniversary symbolizes the idea that the clocks only need to be wound once a year on a meaningful date, such as the date you received the clock.

What does torsion pendulum mean?

noun Horology. a pendulum the weight of which is rotated alternately in opposite directions through a horizontal plane by the torsion of the suspending rod or spring: used for clocks intended to run a long time between windings.

What cause a pendulum to come to a stop?

A pendulum stops oscillating because it loses energy when it is converted into heat. Even without air friction, the friction which exists with the point around which the pendulum rotates causes the system to lose kinetic energy and eventually stop.

Why does my anniversary clock keep stopping?

The spring being bent is the number one cause for most of these clocks not working. … First there is the brass bottom block that the Anniversary Clocks Pendulum balls attach to. Then in the upper middle of the spring there is the fork attachment that whacks the verge back and forth.

Article first time published on

How do I wind my Elgin clock?

The most effective way to wind your clock would be to open the front door, insert the crank, hold the clock steady with your left hand, and turn the crank with your right hand. After winding the clock, set the correct time by moving the minute hand either clockwise or counterclockwise.

What is an antique bracket clock?

A bracket clock is a style of antique portable table clock made in the 17th and 18th centuries. The term originated with small weight-driven pendulum clocks (sometimes called ‘true bracket clocks’) that had to be mounted on a bracket on the wall to allow room for their hanging weights.

What is a clock crutch?

The crutch is the wire part fixed to the clock at the back of the movement, usually bent at a right angle at the bottom, with a rectangular hole in it for the pendulum rod to slide through. If you touch it you will see it can move from side to side through an arc.

Why is it called an anniversary clock?

The “anniversary clock” is called that because it’ll run for about 400 days on one winding, so you can wind the thing on your wedding anniversary, perhaps making a celebration of the ritual.

Where do you wind an anniversary clock?

To wind your anniversary clock, gently turn the winding key counterclockwise three or four turns. Once the key can no longer turn, your clock is wound for the next 400 days.

How do you slow down an anniversary clock?

To slow down the clock, loosen the adjustment nut (turn it toward your left). The bob will settle lower, making the effective length of the pendulum longer. The clock will run slower. To speed up the clock, tighten the nut (turn it toward your right).

How much does it cost to fix anniversary clock?

$350 – $450 typical price to overhaul the movement and replace the suspension spring. Two year warranty. The suspension spring is the thin flat wire that the pendulum hangs on. (I give a price range to allow for parts or extensive repairs that may be needed.

How do you set the time on a Schatz clock?

Remove the glass or plastic dome from the Schatz 1000 day clock. Hold the dome with both hands and lift it straight up until the bottom of the dome clears the top of the clock. Set the clock in an area free from movement or vibration.

How do I keep my pendulum swinging?

1. Make it heavy (and, specifically, dense). The more mass a pendulum has, the less outside influences such as air resistance will degrade its swing.
2. Put it in a vacuum. …
3. Use an escapement mechanism. …
4. Give it a large initial swing.

What causes a pendulum to eventually slow down and stop swinging?

When the swing is raised and released, it will move freely back and forth due to the force of gravity on it. The swing continues moving back and forth without any extra outside help until friction (between the air and the swing and between the chains and the attachment points) slows it down and eventually stops it.

Why won't the pendulum keep swinging?

Often a pendulum clock will stop when it has been moved, bumped or even a too aggressive push to restart a pendulum. It is not broken, only out of beat. This only takes a few minutes to readjust and all pendulum clock owners should learn how as this will happen eventually.

How do you fix a clock that won't tick?

First, stop the clock by holding the pendulum in the central position. Then carefully move it first to the right, until it ticks. (If it doesn’t tick, move it to the left, instead). Then do the same on the opposite side.

How do you adjust a pendulum clock?

Stop the pendulum to move the pendulum bob up or down to change the pendulum’s effective length. If the clock is running fast, move the bob down or turn the nut to the left. If the clock is running slow, move the bob up or turn the nut to the right. Restart the pendulum and reset the clock hands to the proper time.

What force stops a pendulum from swinging?

The standard answer would be that gravity is the force that causes a pendulum to stop swinging.

What is the difference between simple pendulum and torsional pendulum?

In a simple pendulum, the oscillating mass has dimensions much smaller than the distance between the axis of suspension and the centre of gravity. … A torsional pendulum is an oscillator for which the restoring force is torsion.

Why is a torsion pendulum useful?

Torsion pendulums are often used for time-keeping purposes. For instance, the balance wheel in a mechanical wristwatch is a torsion pendulum in which the restoring torque is provided by a coiled spring.

What is the bar pendulum?

Bar pendulum is called compound pendulum because a compound pendulum has extended mass, just like as a swinging bar. A bar pendulum is the simplest form of compound pendulum. It is in the form of a rectangular bar with holes drilled along its length at equal separation.
