Calling before you dig ensures that any publicly owned underground lines will be marked, so that you can dig around them safely. Having the utility lines marked not only prevents accidental damage to the lines, but prevents property damage and personal injuries that could result in breaking a line. Also, it’s the law!

How does Dial Before You Dig work?

Anyone wishing to excavate lodges an enquiry with Dial Before You Dig at least two days prior to the excavation. Once the information is entered into the system, our program determines which members have an asset or interest in the excavation site, and sends a notification known as a referralto them.

How do I check my pipes before digging?

811 is the national call-before-you-dig phone number. Anyone who plans to dig should call 811 or go to their state 811 center’s website before digging to request that the approximate location of buried utilities be marked with paint or flags so that you don’t unintentionally dig into an underground utility line.

How long is 811 good for?

Agriculture and 811 Safety. Excavation work in California, which includes agricultural activities, has required a “call before you dig” ticket since the 1980’s. Standard tickets are valid for 28 days and can be renewed if work is ongoing.

How deep are electrical lines buried?

In addition, National Codes dictate the depth, below ground, these lines must be buried. Some low voltage underground circuits could be as shallow as 18 inches, while most higher voltage circuits will be deeper than 24 inches.

What do the 811 colors mean?

for temporary marking of underground utilities. RED – Electric Power Lines, Cables, Conduit, and Lighting Cables. YELLOW – Gas, Oil, Steam, Petroleum, or Gaseous Material. ORANGE – Communication, Alarm or Signal Lines, Cables, or Conduit. BLUE – Potable Water.

Is there a penalty for not calling 811?

California State Law Says, You Must Contact DigAlert Before You Dig! Failure to do so can result in fines up to fifty thousand dollars and you could be charged with the repair costs of damaged underground facility. Why risk it?

How do you find underground utilities?

Ground Penetrating Radar (GPR) is an important tool for locating underground utilities. GPR can locate non-metallic utilities that other locating equipment cannot. GPR uses different microwave energy frequencies to obtain data from different depths but usually 400-MHz is used for utility location.

Whose responsibility is it to call 811?

Property owners can call 811 requesting private locates for any non-utility owned facilities (such as underground power or gas lines to an outbuilding). If you expose gas or electric lines that haven’t been marked, or damage a line, stop excavating and call the utility immediately.

How deep is the gas line in my yard?

On average, main gas lines are usually found at least 24 inches deep, while service lines are usually 18 inches deep.

Article first time published on

Does underground wire need to be in conduit?

There’s one restriction: It needs a conduit where the cable is exposed on the outside of the house and to 18 inches below the ground. Burying the cable 24 inches requires more digging, so this method only makes sense if you have easy-to-dig soil or are renting a trench digger.

Can power go out if lines are underground?

But all power lines lose some of the electricity they carry as heat – and if this heat builds up, it ultimately restricts the line’s ability to carry power over longer distances. Air effectively dissipates heat from above-ground lines, but buried lines are more vulnerable to heating.

How close to underground wires can I plant a tree?

Tall growing trees should be planted a minimum of 20 feet away from power lines, and 50 feet away to avoid future pruning. A mature height of less than 15 feet is recommended for trees planted near power lines. Do not plant near underground utility services.

What should be done prior to notifying DigAlert?

1. Delineate or pre-mark their work area in white (paint, chalk, flour, flags, etc.)
2. Contact Us and give at least two (2) working days NOT including the date of notification (4216.2(b)) prior to excavating.
3. Hand dig to expose utility lines to the point of no conflict within the tolerance zone.

How deep can I dig without calling Julie?

TREES AND SHRUBSFENCINGDECKS AND PATIOSROOM ADDITIONSSWING SETSMAILBOX POSTSSIGNS AND SHEDSGARDENSFOUNTAINSSWIMMING POOLS

How deep are Oregon water lines buried?

Underground piping systems shall be installed a minimum depth of 18 inches (305 mm) below grade, except as provided for in Section C404. 10.1.

Why is USA spray painted on the ground?

In response to the submitted USA the utility providers come out and mark any conflicts within the excavation box. These are colored coded, e.g. blue for water and green for sewage.

Why did Miss utility Mark my yard?

Utilities will mark their buried lines on your dig site. State laws vary, but generally, utility companies have a few days to respond to your request. Utilities will send out locators who will come to your dig site to mark the approximate location of buried utilities with paint or flags so that you can avoid them.

What color is sewer water?

Water Lines:Raw waterOlive GreenWaste Lines:Sewer (sanitary or other)Dark GrayOther Lines:Compressed AirDark GreenGasRedOther PipesLight Gray

How do underground cable detectors work?

To detect the magnetic fields emitted from a buried utility, the locator uses aerials built up of wire wrapped around ferrite rods. The aerials are used to amplify the small electromagnetic signals emitted by the utility and to provide an input to the locators’ circuitry.

Will a metal detector find buried electrical wire?

Short answer, yes they do! Most metal detectors can identify underground cables as long as they are buried within your machine’s range. A detector’s signal will easily penetrate the plastic pipe and detect the metallic wire inside the power line.

How do underground wire locators work?

Since its development, the cable locator has generally consisted of two parts – a transmitter and a receiver. The transmitter puts an electrical signal onto the cable being traced, while the receiver picks up that signal, allowing the locator operator to trace the signal’s path and follow the cable being located.

How deep are gas and electric lines buried?

Main lines are usually found at least 24 inches deep, while service lines are usually 18 inches deep. The current depth of an electric or natural gas line can be different than when it was first installed.

Which is the best way to locate buried services?

The simplest and most efficient way to excavate an area safely is to employ trained professionals to scan and mark it up before each excavation. In most cases for the accurate scanning cable avoidance tools should be used. These cable locators basically consist of two-parts: a transmitter and a receiver.

Can you bury a gas line?

How Deep Does A Gas Line Have To Be Buried? Generally the depth of your ditch should be 18 to 24 inches. The type of terrain will have something to do with the depth. Always check with your local building department for specific code regarding depth of your ditch in your area.

Can I plant a tree near a gas line?

Tree planting around underground utilities should always be carefully managed to minimize problems and trees near gas lines raise particular issues. Tree roots present a concern for the integrity of a gas line, such as damaging its resistance to corrosion and interfering with the visibility of the right-of-way.

Can you bury Gas and Electric together?

If trench is to be a joint trench (shared with other utilities) the following separations must be maintained: 24 inches between gas and electric lines. … 24 inches between sewer and electric lines. 12 inches between communications and electric lines.

Can you direct bury so cord?

Since it is subject to physical damage, it is not allowed as a direct burial. UF cable is used for direct burial. “SOOW” cord is not rated for direct burial on the exterior insulation.

Can I bury an extension cord?

In general, you can’t bury the outside extension cord. Using a standard extension cord is designed initially only for temporary use. Instead, you can use a more suitable cable type for any permanent outdoor purposes, such as a direct burial UF cable.

What is the minimum burial depth for PVC conduit?

An underground electrical service underneath a parking lot would need to be buried at a depth of 24” no matter what type of wiring method was used. An installation in PVC under a building’s concrete slab would basically have no burial depth.

Why does electricity go off during rain?

When there is a rain or wind flows heavily then mostly trees and their heavy branches are broken which falls on distribution lines. As a result conductors are short circuited which trips the protecting coil at the grid as a result supply is disconnected.
