For example, an upright sprinkler in an ordinary hazard environment can be as far as 15 feet from an adjacent head. That same head can be up to half that distance—as far as 7.5 feet—from a wall.

How can I make my sprinkler spray farther?

Using a wrench or a screwdriver, rotate the screw – clockwise to increase distance and counter-clockwise to decrease distance. While turning the adjustment screw, be sure to do so in small increments until you reach your desired distance.

What is sprinkler radius?

Rule: Sprinkler Radius = distance between sprinklers. One more time: The water from any single sprinkler should actually get the sprinklers on each side of it wet! … For example, 15′ radius spray heads should never be more than 18′ apart (30′ diameter x 0.6 = 18′).

What is the coverage area of a sprinkler?

Hazard LevelCoverage (in sq ft) per Sprinkler HeadMaximum Allowed Distance Between Sprinkler HeadsExtra Hazard 1 & 2 (areas with a high concentration of flammable materials)90-130 sq ft per head (based on obstructions and flow calculationss)12 ft

How far can a sidewall sprinkler spray?

Distance from Sidewall Sprinkler to Side of Obstruction (A)Maximum Allowable Distance of Deflector Above Bottom of Obstruction (B) [in. (mm)]5 ft 6 in. (1.7 m) to less than 6 ft (1.8 m)3 (75)6 ft (1.8 m) to less than 6 ft 6 in. (2.0 m)4 (100)6 ft 6 in. (2.0 m) to less than 7 ft (2.1 m)6 (150)

How far does a pop up sprinkler spray?

The most basic pop-up sprinkler is a stationary head. Typically spraying one dedicated area up to 15 feet away, these heads produce a fine mist at 90-, 180- or 360- degree angles. Some models have fixed nozzle angles, while other types have adjustable heads for more versatility.

How close can a sprinkler head be?

In a nutshell, NFPA 25: Standard for the Inspection, Testing, and Maintenance of Water-Based Fire Protection Systems says that objects that can block a sprinkler’s spray must be at least 18 inches away from the deflector.

How far does a sprinkler head need to be from a wall?

All standard spray sprinklers have four-inch minimum spacing from walls and maximums that vary with room shape and size. All standard sprinkler heads—pendent, upright, and sidewall—have the same minimum sprinkler distance from walls: four inches.

How close should sprinklers be to the house?

Check your system’s design. Make sure sprinklers don’t spray your house, especially the windows, or over window wells. Keep the spray at least 2 feet away from the house.

How long should you water your lawn?

It is ideal to water lawns about one inch of water per week. To determine how long you need to water to get one inch, place a plastic container in your yard and set a timer. On average, it will take 30 minutes to get a half inch of water. So, 20 minutes, three times per week will give a lawn about an inch of water.

Article first time published on

How many sprinkler heads can you put on a zone?

At different pressures, the sprinkler head and nozzle will consume different amounts of water. For example, at 35 pounds per square inch (PSI) the 5000 Series Rotor using the 3.0 nozzle will use 3.11 gallons per minute (GPM). If your home’s water capacity was 10 GPM, you could place 3 heads per zone.

How do you rotate Rain Bird sprinklers?

Grip the spray head between two fingers. Then, rotate it by hand so it is aimed at the direction you want the water to spray. For example, if you want the water to spray towards the right, rotate the head to the right. If you want the water to spray more to the left, rotate the head to the left.

How close can a smoke detector be to a sprinkler head?

After all, a sprinkler head is nothing more than a heat detector that allows water to flow. The listed spacing for heat detectors varies depending on the type of detector and its rated temperature, although the most common listed spacing is 50 feet between detectors.

What is the coverage of a sidewall sprinkler?

With their coverage up to 16 ft (4,9 m) wide by 24 ft (7,3 m) long, they are designed for installation along a wall or the side of a beam and just beneath a smooth ceiling.

How far do sprinkler heads spray?

Types of Sprinkler Heads Spray heads: Best used for small to medium sized lawns and/or in systems that will be operating with pressure between 20 – 30 PSI. Because of the lower PSI the distance of the spray rarely exceeds 15ft. Meaning that spray heads should never be placed further than 15 ft.

How many zones are in a bubbler?

The water infiltrates into the soil and wets the root zone. The water is applied through bubblers. These are small emitters placed in the basins which discharge water at flow rates of 100–250 litres/h. Each basin can have one or two bubblers as required.

How much clearance space is required below any sprinkler head?

Question 1: 29 CFR 1910.159(c)(10) in part states, “The minimum vertical clearance between sprinklers and material below shall be 18-inches (45.7 cm).” Does this apply only to materials placed directly below the sprinkler heads?

Is it okay for sprinkler to hit house?

Over-spray: When the sprinklers hit the house, it’s not only a waste of water but also often leads to moisture damage to the paint, stucco and structural members of the home. … Conversely, if a portion of your garden or lawn appears dry or needs extra water, turn the screw counterclockwise.

How many zones does my sprinkler system need?

Draw Your Sprinkler Zone Plan With simple math, you can determine how many heads in each zone and then take the total number of sprinklers you need, and divide that by your head/zone number and that will tell you how many zones you need.

Is it bad for sprinkler to hit house?

One of the most serious problems that homeowners face is from their outdoor automatic sprinkler systems. Improperly installed sprinkler heads can damage concrete, stucco and siding on your home. … Over time, water that continually hits the home can loosen brickwork, damage stucco, erode concrete and ruin paint.

What is the maximum height of sprinkler head?

The answer, like so many great engineering answers, is “it depends.” Experience and testing have shown sprinklers to be effective and necessary at heights in excess of 50 feet. For this reason, most installations should not have a limit on the height they can be installed.

How often should I water my lawn in 90 degree weather?

For best results, water your lawn thoroughly three times a week if we do not get significant rainfall. In hot, dry weather, water shrubs and flowers daily. Morning, around 6 to 8 a.m., is the best time to water. Watering at any time of day is better than not watering at all.

Why is it bad to water grass at night?

Although it might seem smart to wait until night, when temperatures are cooler, watering in the evening keeps lawns wet overnight, which can make the grass susceptible to disease. … “A wet lawn at night is the perfect condition for fungus to grow.

How long should each sprinkler zone run?

A watering session should be long enough to soak the area sufficiently so all the roots receive a beneficial drink. Sprinklers should be set to run for about 30 to 35 minutes at a time twice a week.

Why do oscillating sprinklers get stuck?

Water Pressure or Water Volume If the water level is too low, the distribution bar on an oscillating sprinkler may be unable to move at all, or it may move very slowly to the end of the cycle, then be unable to move past the pivot that sends it back in the opposite direction.

What is the best sprinkler for low water pressure?

• The Overall Best Lawn Sprinkler For Low Water Pressure. Melnor 65003-AMZ Oscillating Sprinkler. …
• The Best Lawn Sprinkler For Water Pressure As Low As 15 PSI. …
• The Best Budget Lawn Sprinkler For Small Lawns. …
• A Durable Lawn Sprinkler That Comes In 5 Colors.

How much PSI does a sprinkler need?

Water pressure is measured in pounds per square inch – also called psi. The average water pressure for most homes and businesses is between 30 psi and 50 psi; most sprinkler systems are designed to use pressures of around 30 psi.

How deep should Lawn sprinkler pipes be buried?

Dig for Your Sprinkler System The trenches will be relatively shallow, usually 6 to 12 inches deep, depending on your area’s freeze cycles and frost severity. The trench must also be deep enough to allow the sprinklers to retract underground to prevent breakage from lawn machines.

How many sprinklers can I run on one line?

For example, you generally have a flow rate of 10 gpm from a ¾-inch spigot where you connect your hose. With your 10 gpm flow rate at your spigot, you could run two sprinklers at 5 gpm each. The best set-up is to run two hoses from the spigot–each to one sprinkler.
