Determine the thickness required for the LP LVL beam and calculate the maximum reaction. 2. Select the appropriate table for 1-ply (1-3/4″), 2-ply (3-1/2″) or 3-ply (5-1/4″).

How big should my LVL beam be?

Design a beam width based on the fact that the typical width of an LVL beam is 1 3/4 inches. The width can be increased by laminating in multiples of 1 3/4 inches. Beam width should be 1/4 to 1/3 beam depth.

How thick is a 4 ply LVL?

Laminated veneer lumber or LVL are available in 1 ply of thickness 1 -3/4″, 2 ply lvl of thickness 3 -1/2″, 3 ply lvl of thickness 5 -1/4″ and 4 ply lvl of thickness 7 inches wide.

How far can you span a LVL beam?

Due to its strength, an LVL beam can span up to 60 feet and is much stronger than traditional lumber. Generally, you can find LVL beams in 4-foot increments starting at 24 feet and going up to 44 feet long, with special orders up to 60 feet. LVL beam thickness is usually between 1 ¾ and 7 inches.

Can LVL span 30 feet?

What size lvl beam for a 30 foot span:- as per general thumb rule, for a 30 foot span, size of LVL beam or GLULAM should be 16-18 inches deep and 4 inches wide, thus you need something like a 16-18″ GLULAM or LVL to span upto 30 feet used for residential building or projects.

What size LVL Do I need to span 24 feet?

LVL beam size for a 24 foot span:- as per general thumb rule, for a 24 foot span, size of LVL beam or GLULAM should be 12-14 inches deep and 4 inches wide, thus you need something like a 12-14″ GLULAM or LVL to span upto 24 feet used for residential building or projects.

What size LVL Do I need to span 20 feet?

What size lvl beam for a 20 foot span:- as per general thumb rule, for a 20 foot span, size of LVL beam or GLULAM should be 10 to 12 inches deep and 3 inches wide, thus you need something like a 10-12″ GLULAM or LVL to span upto 20 feet and can use simple 2×14 dimensional lumber at 16″ apart from centre as floor joists …

Is LVL stronger than dimensional lumber?

Laminated veneer lumber (LVL) studs can be two times stronger in compression and tension than standard framing lumber of the same dimension.

How far can you span a 2x12 LVL?

A 2×12 with an E of 800,000 psi and Fb of 790 psi also works, since it can span 15 feet and 10 inches. Given a design span of 15 feet 1 inch and a 16 inch joist spacing, first determine which size lumber will work.

Do LVL beams sag?

Your wood/LVL will sag much more. What you are describing is ultra typical when there is a point load above and they used LVL. I don’t know why cities keep allowing the use of LVL for anything more than 10 feet. It will look great and then year 2-3 it starts sagging… year 4-5 you get cracks and notice it…

Article first time published on

What size LVL Do I need to span 16 feet?

What size lvl beam for a 16 foot span:- as per general thumb rule, for a 16 foot span, size of LVL beam or GLULAM should be 7 to 8 inches deep and 3 inches wide, thus you need something like a 7-8″ GLULAM or LVL to span upto 16 feet and can use simple 2×10 dimensional lumber at 16″ apart from centre as floor joists …

How much does a LVL beam cost?

LVL beams cost on average $3 to $12 per linear foot for the material or $50 to $200 per foot installed. LVL beams are more cost-effective and durable than regular wood beams.

Can you screw into LVL?

Whenever possible, avoid drilling vertical holes through LVL beams unless the beam width is at least 3-1/2 inches. Prior to drilling any vertical holes, an engineer or architect qualified in wood design should be consulted.

How much do LVL beams weigh?

Weight of LVL (Laminated Veneer Lumber)↓1/4 inch24″1 inch0.07 lbs6.831-3/4″0.13 lbs11.963-1/2″0.25 lbs23.92

What is LVL beam?

Laminated veneer lumber (LVL) is an engineered wood product that uses multiple layers of thin wood assembled with adhesives. It is typically used for headers, beams, rimboard, and edge-forming material. … Due to its composite nature, it is much less likely than conventional lumber to warp, twist, bow, or shrink.

How much does a LVL beam cost per foot?

LVL beams cost $3 to $12 per linear foot on average. LVL beams are more affordable and stronger than wood beams. They’re also fire-resistant, shrink-proof, and easy to install in long lengths.

What size beam do I need for a 15 foot span?

Wood beam size for a 15 foot span:- as per general thumb rule, for a 15 foot span, size of wood beam or lumber joist should be 2×10 which placed at 16″ apart from centre used for residential building or projects or construction in which depth of section of beam is 250mm (10″) and width of beam is 50 mm or 2″.

How do you size a load bearing beam?

Measure the depth of your beam and then add an extra half inch. For example, if the beam is 7 inches deep, the support ledger should be set down 7 1/2 inches on the kind studs. This will give room to move the beam into place.

Is glulam the same as LVL?

LVL refers to a manufactured timber product made from thin veneers (often 3mm) glued together to form large structural members, often known as Hyspan or similiar. Glulam is made from thicker sections of timber, generally 15-45mm thick, glued together to form a large variety of products.

What beam can span 20 feet?

Steel beam size for a 20 foot span:- as per general thumb rule, for a 20 foot span size of steel beam or universal beam or w beam or I beam or UB’s or hot rolled section should be ISMB 300 or UB 300×140 (12″×6″) used for residential building or projects or construction in which depth of section of beam is 300mm (12″) …

What size LVL Do I need to span 26 feet?

What size lvl beam for a 26 foot span:- as per general thumb rule, for a 26 foot span, size of LVL beam or GLULAM should be 14-16 inches deep and 4 inches wide, thus you need something like a 14-16″ GLULAM or LVL to span upto 26 feet used for residential building or projects.

What size beam do I need to span 25 feet?

Wood beam size for a 25 foot span:- as per general thumb rule, for a 25 foot span, size of wood beam or lumber joist should be 2×16 which placed at 16″ apart from centre used for residential building or projects or construction in which depth of section of beam is 400mm (16″) and width of beam is 50 mm or 2″.

How much load can a beam support?

The bending moment is the length of the span times the weight to be supported divided by 8. For a beam spanning a 12-foot room and supporting a weight of 600 lbs., the maximum bending moment would be 12 x 600/8 = 900 foot-pounds.

What size beam do I need for an 18 foot span?

What size lvl beam for a 18 foot span:- as per general thumb rule, for a 18 foot span, size of LVL beam or GLULAM should be 9 to 10 inches deep and 3 inches wide, thus you need something like a 9-10″ GLULAM or LVL to span upto 18 feet and can use simple 2×12 dimensional lumber at 16″ apart from centre as floor joists …

What is the difference between LSL and LVL?

LSL is typically less expensive than other engineered wood beams. Due to its high allowable shear strength, LSL beams have the capacity for larger penetrations than other engineered wood beam options. … Laminated Veneer Lumber (LVL) is a commonly available engineered product that is manufactured similarly to PSL.

Can you paint LVL beams?

NelsonPine LVL billets in standard thicknesses come with an industrial type finish that can have normal timber paint and stain systems satisfactorily applied to them.

What are the disadvantages of LVL?

Although its dimensional stability is better than solid wood, the product may result in some defect, such as warping, if it is not properly stored in the warehouse. Also, LVL requires high capital investment to have relatively low production cost.

Is LVL better than solid wood?

Laminated veneer lumber (LVL) studs can provide ultimate strength against wind and shear-loads and can be up to two and a half times stronger than standard framing lumber of the same dimension in compression and tension, which means a wood-framed house can be designed and constructed to withstand 100 mph or more .

What is stronger LSL or LVL?

Because of their laminated structures, LVL and LSL have higher bending strength and stiffness than the equivalent solid timber section of the same species. This section contains the following resource: Laminated Veneer Lumber/Laminated Strand Lumber.

Can LVL beams fail?

It has been reported that it is very difficult to fail LVL in edgewise shear using a prismatic cross section due to the high shear-to-bending strength ratio of the LVL, as compared to other engineered wood products such as glulam [3,4].

How far can a 2x10 LVL beam span without support?

A 2×10 beam – made up of two 2x10s nailed together – can span up to 11′ without support beneath a deck that is 4′ wide. For a more normal-sized deck, the same beam can span 8′, supporting a deck that is 8′ wide.
