Fascias are typically made from 1-inch material, with the width being enough to cover the rafter width. Typically rafters will range from 2×6 to 2×8, although some are larger depending on the roof construction.

What size wood do you use for fascia board?

You construct fascia boards out of 1-by lumber. The width depends on the width of the rafters, but since builders generally use two-by-six or two-by-eight lumber for roof construction, the most common dimensions for fascia boards are one-by-six and one-by-eight.

How thick should soffit board be?

Standard soffit material is 3/8- or 1/2-inch-thick exterior plywood in pine (or similar softwoods) or cedar. Common, but much less durable, is Masonite or similar fiberboard soffit, as well as much more weather-resistant fiber-cement.

What is the best wood for fascia boards?

Many different types of wood are suitable for fascia boards. Spruce, pine and fir are all popular and relatively inexpensive options. However, some roofers prefer to use cedar, cypress or redwood for fascia boards. While they are more expensive, these woods better resist moisture, even when left unsealed.

Should I use treated lumber for my fascia board?

Should the fascia board be pressure treated? – Quora. It’s not necessary to use pressure-treated lumber for fascia. In fact, most planking sold for fascia is not pressure treated. However, it is vital that the fascia be primered and completely painted with a good quality exterior enamel or acrylic paint.

What type of wood is used for eaves?

All About Eave Eaves are simple boxes. The bottom — or soffit — where the damage is, is typically thin plywood, usually 1/4-to-3/8-inch-thick. It’s cut in long sections and butt-jointed together with a thin piece of plastic molding that slips over both ends forming a joint.

What is best material for fascia?

Typically for fascia boards, cedar and redwood are popular choices given their resistance to rot from excessive moisture. However, if you prime and paint the fascia, then fir, spruce, and pine can also make beautiful choices from a design standpoint.

How wide should fascia be?

Fascias are typically made from 1-inch material, with the width being enough to cover the rafter width. Typically rafters will range from 2×6 to 2×8, although some are larger depending on the roof construction. Therefore, the more common fascia board sizes are 1×6 or 1×8.

What kind of nails do you use for fascia?

It calls for 2-inch, 16-gauge, corrosion-resistant finish nails only when you are attaching fascia to double sub-fascia. Nails should not be closer than 1 1/4 inches from the edges and no nearer than one inch from the ends. With pneumatic nailing, Hardie Trim recommends driving the finish nails flush.

How deep should a soffit be?

While not all soffit board sizes are the same, the width of most soffit falls in the range of 16 inches to 24 inches when used to cover the eaves of the home. In addition, standard soffit sizes feature a ¼-inch thickness, too, which can help with installation.

Article first time published on

Can Plywood be used for soffit?

Although unsanded and touch-sanded grades of plywood are often used for soffits, optimum appearance and finish performance is achieved by using panels with Medium Density Overlay (MDO), or textured (such as APA 303 Siding) or sanded A-grade faces. … If a smooth, check-free surface is desired, use MDO plywood.

What is the average cost of replacing fascia boards?

Replacing your soffit generally costs about $20 to $30 a linear foot installed, while replacing your fascia costs about $15 to $25 a linear foot installed. Prices for the project depend on a number of factors, including the materials used and the size of your house.

How much do you overlap fascia?

NEVER ‘face nail’ fascia. DO NOT drive nails tight — fascia must be ‘hung’, only snug to soffit, to allow expansion and help prevent distortion. Allow at least 1” overlap of fascia where lengths meet.

Do fascias or soffits go first?

What is a soffit? Soffit, or soffit boards, are similar to fascia, but instead of running parallel to the walls of the building, they are installed at a 90-degree angle to the walls. Soffit boards are fitted underneath the fascia boards, to fill the gap between the fascia and the wall.

What is behind a fascia board?

Soffit. The soffit board is tucked away under the fascia board. It is usually the board that you see most of from street level. The soffit can be ventilated to allow the flow of air into the roof area.

Can PVC be used for fascia board?

Obviously the biggest reason for using a PVC trim board is long term maintenance combined with traditional architectural appeal. … PVC trim boards will not rot, twist, split or warp. In addition you can leave it unpainted if you like or paint it to match a certain color scheme.

Are fascia boards structural?

The fascia board is the one inch thick board that is nailed to the lower ends of the rafters, roof joists, or trusses to close the eave (Figure FB-1). … Technically it is not considered a structural member, but it provides structural support for the gutters, when they are nailed to it.

How do I protect my fascia board?

To protect and prolong the life of your fascia board, there is an option to have it wrapped with aluminum or vinyl material. Ensuring that no water gets to the wood will allow it to last 20 years or more.

Should fascia be sealed?

Soffits and fascia should be freshly painted and sealed when your gutters are assessed to prevent against future damage.

What is the thickness of Trex fascia?

The actual Trex decking boards are available in 1 or 2 inch thick boards. The three main types of boards are the Fascia, Grooved Edge and Square Edge. The Fascia is available in either 8 inch or 12 inch long boards. The boards are 0.75 inches thick and 11.375 inches wide.

How thick are vinyl soffits?

12” O-Vent Soffit: Vented Triple 4” profile with Single Nail Hem, 12in. wide exposure configured as three 4” panels, thickness 0.039” ± 0.001”, 12ft length. Free air space: 4.18 in²/ft².

What size soffit should I use?

Multiply the total length by the width to obtain the area of soffit needed to fill the gap. For example, if the total eaves length is 110 feet, and the width is 2 feet, multiply 110 by 2. The result, 220 in this example, is the number of square feet of soffit required.

What is the soffit height?

Standard Ceiling Space Soffit space should begin 84 inches off the kitchen floor. This means that a typical soffit for an 8-foot tall kitchen will be 12 inches high.

Can OSB be used for soffit?

Re: OSB Vs Plywood for soffits. OSB resists moisture much better, that’s just a fact, but as mentioned you have the OSB look which is an unattractive finished look to many people. It does take more paint, but not as much as some think unless you expose the wrong side of course.

What is CDX plywood?

CDX Plywood is used primarily by contractors to build exterior walls and roofs. CDX plywood has one side veneer grade “C” and one side veneer grade “D”. The two are bonded together with glue which can withstand a little moisture. The APA would recognize CDX Grade Plywood as C-D Exposure 1 plywood.

What type of material is used for soffits?

Materials Used for a Soffit Board Soffits come from different materials. Some come from woods while others are made of uPVC, wood, aluminum, steel or fiber cement. The first material for soffits is wood. If you want to have an old look for your house, you may choose wooden soffits.

Do roofers replace fascia boards?

Most roofers, in that case, are generally trained to spot problems in fascia and gutters as well the training required to take care of them. … Fascia both keeps the gutters secure and seals the interior of the attic to some degree. Every so often in the lifespan of your home, you will see fascia repair or replacement.

What is the difference between barge board and fascia?

Bargeboards and fascia boards are essentially the same thing. They are both long, straight boards that run along the lower edge of the roof. However, fascia boards run horizontally, carry the gutters and support the bottom row of roof tiles. Bargeboards run diagonally and are located at the gable end of a property.

Do gutters need fascia?

A home without fascia needs to have gutters attached by roof straps. These straps act as a sling for your gutter. They’re fitted to the gutter hanger, and then they are attached directly to the roof.
