It is most often either blue or black, unless the installer did their own rewiring to create a C wire. These are the most common colors and the labels used for thermostat wires: Blue or Black – C – The common wire. Red – R – 24 VAC power from the transformer in your furnace.

How do I know if I have a blue wire or C wire?

It is easy to see if you already have a c-wire connected to your system. Simply remove your current thermostat face from its baseplate and look for the terminal labeled with the letter “c.” If this terminal has a wire attached to it, you have an active “c-wire.”

What's the C wire on a thermostat?

WHAT IS A C-WIRE? A C-wire, or a common wire, runs from your low voltage heating system (24v) and carries continuous power to your thermostat. In today’s electric market, most newer heating and cooling systems have C-wires, which guarantees compatibility for the installation of all smart thermostats.

Is the C wire blue or brown?

The C, or common wire, provides smart thermostats with continual power. It’s usually blue, but it may also be black, brown or purple. The O or orange wire connects to your heat pump (if applicable).

What color are C wires?

Blue wires are also called C wires because they are the Common wire. C wires are necessary for any smart thermostat that needs to be connected to a power source 24/7, regardless of your heat pump type.

Where does blue wire go on Honeywell thermostat?

If you see a blue wire, it’s usually connecting to the C terminal and giving a return path for the red wire. You can find a B terminal that performs the same function as the O terminal on some systems.

What does the C wire connect to?

A common wire (C-Wire) provides Wi-Fi thermostats continuous power by connecting it to a heating and cooling system (e.g. furnace). C-Wires are required on most Honeywell Wi-Fi thermostats, with the exception of the Smart Round Thermostat (formerly known as the Lyric Round).

What color is ob wire?

MarkingWire Color CodeDescriptionOOrangeChange-over relay to cool relayBBlueChange-over relay to heat relayAHeat and cool active to any relayLEmergency heat active lamp

Where does blue wire go in nest?

A brown wire is mostly likely a heat pump wire and should be connected to the O/B connector on the Nest thermostat. If the B wire is blue, it should most likely be connected to the C connector.

What has C wire but no power?

Quick Check for an Existing C-wire: If the thermostat loses power it does not have a C-wire, and you may need an add-a-wire kit. If it doesn’t lose power, locate your breaker panel. Flip the breaker for the wall with the thermostat on it. If it loses power, you likely have a C-wire.

Article first time published on

Where does the C wire connect to a transformer?

Insert one wire into the unused “R” terminal on the thermostat (RC or RH) and the other wire into the “C” terminal. Make sure to cut the red RC/RH jumper on the back of the Sensi face plate. Finally, plug the adapter into a nearby wall outlet.

How do I connect ecobee without C wire?

Even though it comes with an adapter for missing c-wires, ecobee is what we’d pick even for systems with a c-wire. If you’ve got a 24v HVAC system but no C-wire, check out the ecobee product line. Every ecobee ships with an adapter that you can install yourself at your furnace to make up for a missing C-wire.

What is C wire in the military?

Concertina wire or Dannert wire is a type of barbed wire or razor wire that is formed in large coils which can be expanded like a concertina (a small hand-held bellows-type instrument in the same family as the accordion).

What happens if you wire a thermostat wrong?

Potential consequences of improper installation could include: Electric shock. Blowing a circuit breaker. Damaging the thermostat unit, the electrical system or even the AC/furnace unit itself.

What color wire goes where on a Honeywell thermostat?

Meaning of Wiring Terminal Letters W (white) controls the auxiliary heating elements. Y (yellow) controls the compressor on the cooling system. G (green) controls the fan. C (blue or black) provides a return path to the transformer.

What are the 5 thermostat wires?

• Red wire for power (24V).
• White wire for heating (connected to W or W1 terminal).
• Green wire for fans.
• Blue or yellow wire for cooling (connected to Y).
• Black wire for “C” or “Common” wire.

How do you know if a common wire is live?

For example, get a light bulb and socket, and attach a couple of wires to it. Then touch one to neutral or ground and one to the wire-under-test. If the lamp lights, it is live. If the lamp doesn’t light, then test the lamp on a known live wire (like a wall socket) to make sure it actually lights.

What does the blue wire mean?

The blue wire, also referred to as the neutral wire, has the function of transferring electricity away from the appliance. The brown wire, otherwise known as the live wire, transfers electricity to the appliance. The combination of these wires is referred to as a circuit.

Is the C wire a ground?

C stands for common. The common wire is the ground or negative wire. To complete the circuit that provides power to the thermostat you need a positive and negative wire from the 24V transformer.

What a heat pump looks like?

What does a heat pump look like? A: A typical heat pump installation consists of two parts: an outdoor unit that contains the outdoor coil, compressor, reversing valve, and fan; and an indoor unit that contains the indoor coil, supplemental heater and fan. The outdoor unit looks exactly like a central air conditioner.

Is B wire same as C wire?

The common wire, usually labeled C, should go in the C Terminal of the Zen Thermostat. A wire labeled O, B, or O/B is used to control whether a heat pump is in heating or cooling mode. However, on some thermostats, a wire labeled B is the common wire C. In most cases, the common wire is labeled C.

What is the OB wire?

O, B, O/B: These wires are responsible for switching the changeover valve in a heat pump system. The O wire reverses the valve from heating to cooling, and the B wire switches the valve from cooling to heating.

Does my C wire have power?

In that case it will typically be labeled Rh/c. In order to have a circuit that power can flow through, wires need to connect back to the HVAC control board to complete the loop. That’s what the other wires do. So, the c wire doesn’t actually provide the power.

Why am I not getting power to my Nest thermostat?

A “No power” alert can be caused by the following: The thermostat wiring is incorrect. Your thermostat is connected to a system that requires a C or common wire, but that wire isn’t connected. Some systems, including heat-only, cool-only, zone-controlled, and heat pump systems, require a C wire or Nest Power Connector.

How do you hook up a C wire to a boiler?

To get a C wire to one or more of the thermostats, you’ll simply run a wire from the other side of the transformer on the wall. The original wire from the transformer should be connected to the R terminal on the thermostat, while the new C wire should be connected to the C terminal on the new thermostat.

What if there is no C terminal on furnace?

If your furnace does not have a C terminal, you can add a 24V transformer to the furnace, which will make the furnace compatible with a C-wire connection. … Note: If you have both central heat and air, then you’ll need to make a jumper using an 18 AWG wire. Take the wire and connect the Y and G terminals.
