APPLICATION: General: James Hardie believes it is good building practice to seal the joints to prevent moisture, such as wind-driven rain and snow, from penetrating the wall cavity. Caulking around windows, doors, eaves and trim edges gives added insurance that leaks will not occur.

Does Hardie backer board need to be waterproofed?

Hardiebacker (James Hardie): the use of a waterproof membrane, vapor barrier or vapor. retarding membrane is optional unless the local building code requires it.

Can I tile directly on Hardibacker?

The Hardibacker will be fine to tile straight onto.

Do I need RedGard on Hardibacker?

You really don’t need the RedGard, but the more protection the better…so go for it. And yes, you can do the boards beforehand. But, hit the filled seams & screws (your weak points) as soon as a panel is ready to give it some time to setup. You’ll have to wait for the fills to dry or at least setup anyway.

What do you seal backer board with?

The thin-set is a cement-based powder that you mix with water or latex additive to form a thick paste, which is used to seal the seams in the board and can also be used to set the tile.

Will thinset adhere to RedGard?

Premixed thinset mortar does not adhere well to RedGard waterproofing membrane. In order to make sure your tile bonds well to a surface that has been waterproofed with RedGard, use a powdered mortar. You will need to mix this mortar with water yourself, but it will ensure a strong bond between the tile and the wall.

Is HardieBacker better than cement board?

HardieBacker is much more light, and it is also the best selling brand of cement board available. It is much cleaner because it does not have any glass in it. It allows for a smooth job with minimal mess. As a bonus, HardieBacker board has an EZ Grid pattern so you can cut perfect lines.

Can you just screw down cement board?

Screw and Joints Do not use drywall screws as they are not recommended to be used to hold the backer board in place. All of your backer board pieces should be cut before they are placed on​ the floor. … It is important to highlight that screws shall not be installed all the way down to the floor joists.

Can I put RedGard on cement board?

RedGard Creates a Waterproof and Crack Resistant Membrane Applying RedGard to any surface is super easy. … There are two ways to get RedGard on cement board panels: Roll it on the wall with a 3/4 inch nap roller. Trowel it on the wall.

Can you install Hardibacker over drywall?

You can install backer board over drywall, as long as your screws are long enough to go through to firmly penetrate the studs, and then install the stone on the backer board. Better would be to take the drywall off, which is easy to do, and put on backer board in its place to take the stone.

Article first time published on

Can you tile over cement board without waterproofing?

Tile and grout are not waterproof Cement board will not fall apart when exposed to water. But like a concrete walkway, it can soak up water. It can also dry out and be perfectly fine.

What do you do with a gap between tub and cement board?

Technically, after the tile is installed over the backer board that gap between it and the tub ledge should be filled with an ASTM C920 sealant (caulking e.g. silicone). Although some say you should have weep holes along this gap so any water behind can weep out into the tub.

Do you have to tape backer board seams?

For tile backer boards such as Durock, Wonderboard, Hardiebacker, Permabase, and others the seams between the board need to be treated with 2-inch alkali-resistant mesh tape. … It helps to make the walls that are to be tile more monolithic.

Is thinset mortar waterproof?

Thinset is designed to adhere well in a thin layer that’s typically not greater than 3/16″ thick. … Although thin-set is not waterproof, it is isn’t water soluble. When moisture is present, it will not return to a liquefied state as mastic would.

Does cement board need to be sealed?

Contrary to popular thought, tile and grout are not waterproof, and some moisture will penetrate even if sealant is used. … However, if you choose to use concrete backerboard, which is much stronger and more durable than gypsum board, a water vapor membrane must be placed underneath it or a sealant applied on top of it.

How important is Thinset under Hardibacker?

It will make an enormous mess under the house (or whatever is under your bathroom). It is also more likely to make the floor uneven since it is hard to level thinset that is separated by gaps. The installation manual for HardieBacker suggests to embed it in thin-set and it should be installed over plywood.

Can I use Hardibacker on shower walls?

3 Answers. 1/4″ hardibacker alone is an unsuitable substrate for shower wall tile. If it were attached to properly waterproofed drywall, plywood, or plaster it would be fine. Think about it, one wayward elbow, knee, or hip bump and you may get flexion which would cause the grout (or tile) to crack.

What kind of tape do you use for Hardibacker?

Hardibacker 500 inside showers will be taped with Alkali Resistant Mesh tape and thinset. Hardi outside of showers will be taped with ARM tape and joint compound (and textured with all purpose joint compound). –Hardi says not to use paper tape—alkali environment will destroy it. You must use ARM mesh tape.

Can I use drywall mesh tape for cement board?

Apply Mesh Tape Paper tape simply won‘t hold up on cement board. Although paper tape generally leads to a cleaner finish on drywall, you can still achieve a smooth look if you use mesh tape on a drywall/cement board joint. Use this self-adhesive joint tape where cement board and drywall meet.

Can you finish cement board like drywall?

Durock Cement Boards are a type of drywall reinforced with cement for a harder surface. This type of wall material can be finished just like ordinary drywall, using joint tape and joint compound.

Will Hardibacker burn?

It can be used as part of a hour-long fire wall, which is a wall that can resist a fire for up to an hour when properly constructed. Hardiebacker board is generally noncombustible, and the heat produced from the fireplace will not damage it.

Is HardieBacker mold resistant?

HardieBacker boards are water-repellant and mold resistant. However, this is not the same as being waterproof and it means that high moisture can cause damage over time. HardieBacker boards can be used in wet environments, such as bathrooms, but must be used in tandem with a waterproof sealant or another tool.

Can I use Hardibacker outside?

HardieBacker boards are recognized as non-combustible, when tested according to ASTM E 136. Can I use HardieBacker cement board in an exterior application? HardieBacker cement board may be used in some exterior applications, download the installation guide for more details.

Do you have to use mesh tape with RedGard?

You must also tape the backerboard seams with fiberglass mesh drywall tape. The easiest way I have found to install Redgard is, after the walls are prepped properly, start with a paint brush and thoroughly coat all the corners and angles.

What type of thinset should be used with RedGard?

The Flexbond modified thinset, which is sold at HD, lists redgard as one of the surfaces it can be applied to and therefore, following manufacturer recommendations, a person should be using a modified thinset like Flexbond over Redgard.

Can you tile over waterproof membrane?

It is safe to tile over waterproof membrane. In fact, most shower installation systems these days are designed for you to install a waterproofing membrane or waterproof backer board prior to installation. You can also install floor tile directly over the elastomeric membrane.

How long do you let Thinset dry before applying Redgard?

Set the tile into the thin-set while it is still wet. Once the tile is set, do not touch, move, or walk on the tile for 24 hours to allow the thin-set to cure undisturbed.

How do you waterproof drywall above a shower?

Prime the drywall with oil- or shellac-based primer. These coatings protect against moisture better than water-based primer, but they are noxious, so wear a respirator while using them. Spread the primer with a paintbrush or roller and let it dry before painting.

Do bathroom floors need Redgard?

You dont necessarily need it on the bathroom floor but any shower ( wall/floors ) or tub surround must be waterproofed.
