These hurricane clips are also called “seismic ties,” since they reinforce wood frame buildings and reduce the probability of their collapse in earthquakes. Their use is required by building codes in areas subject to earthquakes, even if storms with high winds are rare.

Are hurricane clips necessary?

All new buildings are required to have hurricane ties installed. While not required on older structures, owners of existing buildings would be wise to invest in the installation of hurricane ties and straps. Costs are minimal and these retrofitted items can make a difference during the next hurricane or wind event.

How effective are hurricane clips?

Are hurricane clips effective? Hurricane clips are an effective way of securing potentially hazardous parts of your home in stormy weather. … Roof-to-wall connectors (clips) add a tested, proven, and surprisingly large degree of resistance to wind gusts and steady storm force winds.

What are hurricane clips for roof?

Hurricane Ties, also known as rafter ties, truss ties, or hurricane clips, are used for deck or roof framing to secure rafters, trusses, or joists to the wood framework. This is done to resist uplift and lateral forces, like those that come from a hurricane or severe storm.

What is the difference between hurricane clips and straps?

Clips – Metal connectors that do not wrap over the truss. Strap – Metal connectors that wrap over the truss and are nailed on each side. Double straps – 2 metal connectors that wrap over the truss.

Can you use screws with hurricane ties?

Why not use screws? … However, the risk if construction screws are used in steel connectors such as hurricane tie-downs is that such screws might break under load across the screw diameter even though their screw design resists pulling out of the wood.

How many nails are in a hurricane clip?

On section four of your wind mitigation inspection, your connection may count as a clip if it’s secured to the truss / rafters with three nails. Hurricane clips offer much more protection than “toe nails” – the diagonal nails driven through the side of the roof truss into the top of the wall plate.

How many nails are in a hurricane tie?

The Simpson Strong-Tie H3 Clip is part of the Hurricane Tie System that features various configurations of wind and seismic ties for trusses and rafters. A typical H3 installation ties the single top plate to the rafter or truss. The Simpson H3 requires (8) 8d joist nails.

Do hurricane ties go on both sides?

These ties are designed to attach to connect the wall’s top plate with the truss rafter. For maximum lift resistance, they can be installed on both sides of the rafter or joist.

Can you add hurricane clips to existing roof?

You can install straps that connect to the rafters or trusses right over the top of the wall sheathing. Make sure that the nails hit the double top plate behind the sheathing. If you find fiber board or foam sheathing it will provide almost no connection between the double top plate and the wall below.

Article first time published on

How much do hurricane clips save on insurance?

The simple addition of third nail into hurricane clips can help homeowners save 25-30% on their home insurance premium and provide added security to protect your home if disaster strikes.

How much wind can hurricane clips withstand?

With straps, or clips, a roof can generally sustain winds 120 to 150 m.p.h., Rogers said. “There are many ways to skin a cat,” he said. Metal straps must be tightened as the building frame sets and shifts. Homeowners must also watch corrosion on metal parts exposed to salt air.

How do you tornado proof your house?

1. Secure entry doors. Ensure that entry doors have a two-inch deadbolt lock and three hinges, with screws long enough to secure the door and frame to the wall framing. …
2. Brace garage doors. …
3. Install wind-resistant roof structures. …
4. Protect important documents and valuables. …
5. Prepare your home shelter.

What are roof toenails?

Toenails – This means the trusses in the attic are attached to the walls of the home with nails driven in at angles called toenails. ( No insurance credit for this type of attachment) Clips – This is the first type of roof-wall attachment that receives an insurance credit. Most older homes will qualify for clips.

How do you protect your roof from a hurricane?

1. 1) Nail Down Loose Shingles. Not all shingles are completely uniform. …
2. 2) Roofing Cement on Shingles. …
3. 3) Construction Adhesive on Rafters and Trusses. …
4. 4) Reinforce Your Flashing. …
5. 5) Hurricane Clips or Tie-Downs.

Are hurricane straps required in Florida?

Q: Are hurricane straps required in Florida? Yes. After 1992’s Hurricane Andrew, Florida’s building code was updated to require that all new construction (including both timber and concrete), be equipped with hurricane ties.

How much are hurricane clips?

Tie down hardware, also known as hurricane clips, can be installed for under $10. A house sized 40′ x 30′ requires approximately 42 pieces, so providing added assurance with tie down hardware would cost between $200 and $400.

Do you need roof straps?

Whatever you know them as, they are necessary for the restraint of floor and roof structures to walls. This is usually to stop bulging or cracking of walls, with the most common cause being repeated wind pressure. However, having proper vertical and horizontal restraint straps in place will stop this issue.

What kind of nails do you use for hurricane clips?

While many hurricane ties have been evaluated with 8d x 1½” nails for compatibility with nominal 2x roof framing, some require the use of a longer, 8d common (2½” long) nail and others require a larger-diameter 10d nail.

What nails do I use for joist hangers?

Outdoors use 16d double-dipped galvanized nails (or stainless steel when called for) for installing hangers. It’s true that hot-dipped galvanized box nails aren’t as thick as common nails, but they are the acknowledged choice for outdoor work. Indoors or out, for standard-type single joist hangers, use only 1-1/2 in.

Are hurricane ties required on decks?

Hurricane ties will not usually be required by your local building department, but they are a cost-effective method of securing your joists over a cantilevered beam that may be lifted by high winds.

Are hurricane ties reversible?

The RT7AT Hurricane Tie universal design connects a wide variety of roof framing members to a double top plate. … The reversible design simplifies installation eliminating the left and right connector versions and confusion in the field.

What are hurricane tie downs?

Tie-downs are systems of heavy-duty straps and anchors designed to stabilize manufactured homes (also known as mobile homes) during high winds. … Manufactured homes are elevated and vulnerable to the forces of wind uplift if they are not equipped with skirting.

What does a third nail mean in roofing?

“The third nail is literally a third nail,” said Jason Evilsizer of LGT Restorations. The Fort Myers-based roofer specializes in putting the third nail into roof-to-wall connectors, which makes a roof more secure against heavy wind. Most homes in Florida built before 2002 only use two nails.

What are roof clips?

To begin, let’s define a clip: It’s a concealed anchor that attaches a metal panel to the substrate (roof deck or other material beneath the metal panels) with the use of fasteners. Clips are sometimes referred to as cleats as well. Clips can come in a variety of metal materials and gauges, including: Galvalume®

Is wind mitigation required in Florida?

A wind mitigation inspection is a visual examination of a home’s existing ability (or lack of ability) to withstand damage during a windstorm. … Surprisingly, as of November 2019, wind mitigation inspections are not required in the state of Florida.

What is third nail wind mitigation?

Third Nail Mitigation is a hurricane strap retrofit company servicing all of Florida. We offer truss strap mitigation services that qualify homeowners for a 20%-50% annual reduction of their home insurance premium.

What is a hurricane anchor?

The Hurricane Boat Anchor was specifically designed to make anchoring your boat quick and easy, allowing you to make the most of your time on the water! Many leading anchors require a long length of chain and a 5:1 or 7:1 scope for their anchor to perform in even a moderate wind.

How do I keep my roof from blowing off during a hurricane?

Another beneficial measure for preventing roof blow off involves the use of hurricane roofing clips. Your roofer should also ensure the roof coating is tightly secured. These measures can be retrofitted to your existing roof, but in some cases, having your roof replaced is the best option.

Is a brick house safe in a hurricane?

For centuries, buildings constructed of brick have withstood the ravages of hurricanes, tornadoes, high winds, hail and punishing rain. When used in conjunction with modern building codes, brick homes can remain standing when others on the same block might be destroyed.

Are hurricane clips required in Hawaii?

Hurricane clips are mandated for new construction, additions, and remodels. They are urged by hurricane insurers for existing homes built before 1994 in Hawaii (1994 is the date that the code was fully enforced). … Once the winds have access to the inside of the house then it finishes off the lifting of the roof.
