Condensers are used in air conditioning, industrial chemical processes such as distillation, steam power plants and other heat-exchange

What is the use of a condenser in distillation?

The condenser cools these vapors condensing them back to liquid droplets that flow down the condenser into the receiver flask. A completely filled condenser provides maximum cooling therefore allowing for maximum recovery of the purified liquid during distillation.

What is the use of condenser for reactor?

A large heat exchanger designed to cool exhaust steam from a turbine below the boiling point so that it can be returned to the heat source as water. In a pressurized-water reactor, the water is returned to the steam generator. In a boiling-water reactor, it returns to the reactor core.

What is the purpose of using condenser Mcq?

What is the purpose of using a condenser? Explanation: Condenser is used to convert vapor refrigerant discharging from the compressor into liquid refrigerant by rejecting or removing heat and attaining the saturated liquid line for the refrigerant.

Why is a condenser used to separate water from ink?

This is a process of separating two substances mixed together. Water vaporizes at a lower temperature than the ink pigment so if you heat them, the water evaporates, leaving the ink pigment in the flask.

What is the function of condenser in steam power plant?

A surface condenser or steam condenser is a water-cooled shell and tube heat exchanger used to condensate the exhaust steam from the steam turbine in thermal power stations: the steam is converted from gaseous to liquid state at a pressure level below atmospheric pressure.

What is the use of condenser in steam power plant?

In thermal power plants, the purpose of a surface condenser is to condense the exhaust steam from a steam turbine to obtain maximum efficiency, and also to convert the turbine exhaust steam into pure water (referred to as steam condensate) so that it may be reused in the steam generator or boiler as boiler feed water.

What's an AC condenser?

A condenser (or AC condenser) is the outdoor portion of an air conditioner or heat pump that either releases or collects heat, depending on the time of the year. … In heat pumps, the hot gas is pumped directly to the evaporator coil to provide heat.

Which among the following is most commonly used condenser?

Shell and tube condenser: This is the most common type of condenser used in systems because of its large range of application. In these condensers, the refrigerant flows through the shell while water flows through the tubes in single to four passes. The condensed refrigerant collects at the bottom of the shell.

What are the different types of condenser?

A condenser’s function is to allow high pressure and temperature refrigerant vapor to condense and eject heat. There are three main types: air-cooled, evaporative, and water-cooled condensers.

Article first time published on

What is the condenser capacity unit?

Condensing capacity defines the amount of fluid that the condenser is designed to condense, measured in pounds per hour (lb/hr). Coolant capacity or refrigerant capacity defines the amount of refrigerant that the condensing unit holds.

Why is condenser so called?

Capacitors and capacitors are components used in electrical circuits that can store charge. … it is called a condenser because its function is similar to that of the “mechanical condenser” which converts a large vapor into a smaller volume of liquid.

Where is distillation used?

Distillation is the process of separating components of a mixture based on different boiling points. Examples of uses of distillation include purification of alcohol, desalination, crude oil refining, and making liquefied gases from air.

What is filtration used to separate?

Filtration is used to separate an insoluble solid from a liquid. It is useful for separating sand from a mixture of sand and water, or excess reactant from a reaction mixture.

Why is a condenser used in a Rankine Cycle?

Originally Answered: Why is a condenser used in a Rankin cycle? A condenser is used to convert the steam from the exit of the turbine to saturated liquid. This is done so that we can use a pump to pressurize the liquid. There is no mechanical device till date which can work on steam+liquid mixture.

What are the advantages of condenser?

Advantages of a condenser in a steam power plant It increases the efficiency of the power plant due to increased enthalpy drop. It reduces back pressure of the steam which results in more work output. It reduces temperature of the exhaust steam which also results in more work output.

What is condenser in boiler?

The condenser is a heat exchanger which removes the latent heat from exhaust steam so that it condenses and can be pumped back into the boiler. The feed system completes the cycle between boiler and turbine to enable the exhausted steam to return to the boiler as feedwater.

What are the advantages and disadvantages of condensers?

• Air cooled condensers are simple in operation.
• They are smaller in size.
• Required maintenance of air cooled condensers is low.
• Cleaning process is easy.
• Installation cost is comparatively less.
• Design of air cooled condensers are less complex.

Which condenser is used in window AC?

The condenser is made up of copper tubing and it is cooled by the atmospheric air. The condenser is covered with the fins to enable faster heat transfer rate from it. The capillary tubing made up of various rounds of the copper coil is used as the expansion valve in the window air conditioners.

Which type of condenser is used in domestic refrigerator?

For domestic refrigeration appliances and small commercial refrigeration systems, the fan-cooled condenser is, normally, only used in connection with fan-cooled condensing units which consist of a condenser, a fan, and a compressor (see fig. 17).

What type of condenser is refrigerator?

Detailed Solution. In the natural convection air cooled condensers, large condensing surface area is required as the circulating air quantity is less. This type of condensers is used in domestic refrigerators, deep freezers and other small capacity applications.

Why is the evaporator used?

An evaporator is a device used in a process to turn the liquid form of a chemical substance, such as water, into its gaseous form – vapor. The liquid is evaporated, or vaporized, into a gas form of the targeted substance in that process.

Is capacitor and condenser same?

Condenser and capacitor are one and the same viewed from electrical perspective. … Energy in capacitors is stored in the electric field, while in the case of condensers energy is stored in the electrostatic field (they work as heat capacitors).

What is the difference between a condenser and a compressor?

The compressor “squeezes” the gas. … It actually changes the gas refrigerant into a liquid, which is used throughout the A/C system to eventually produce cold air. The condenser is responsible for taking the pressurized gas from the compressor and changing it into a liquid vapor.

Is a condenser a heat exchanger?

A condenser can be considered a form of heat exchanger as it is similar to a chiller heat exchanger in function.

What kind of energy is a condenser?

Energy stored in a capacitor is electrical potential energy, and it is thus related to the charge Q and voltage V on the capacitor.

What is condenser PDF?

The Condenser removes the heat from refrigerant carried from evaporator and added by compressor and converts the vapour refrigerant into liquid refrigerant. ∎ It is an Heat Exchanger in which heat transfer takes place from high temperature vapour to a low temperature liquid with help of cooling like air or water.

What is condenser in electrical?

From Wikipedia. A capacitor (originally known as a condenser) is a passive two-terminal electrical component used to store energy electrostatically in an electric field. The forms of practical capacitors vary widely, but all contain at least two electrical conductors (plates) separated by a dielectric (i.e., insulator) …

Where are distillation columns used?

A distillation column is an essential item used in the distillation of liquid mixtures to separate the mixture into its component parts, or fractions, based on the differences in volatilities. Fractionating columns are used in small scale laboratory distillations as well as large scale industrial distillations.

Is distilled water to drink?

Is Distilled Water Safe to Drink? Distilled water is safe to drink. But you’ll probably find it flat or bland. That’s because it’s stripped of important minerals like calcium, sodium, and magnesium that give tap water its familiar flavor.

How is distillation used in medicine?

Within the pharmaceutical industry, distillation is generally utilized to efficiently remove one or more solvents or to exchange solvents in preparation for isolation of an active ingredient or intermediate.
