Sometimes called “film replacement technology”, Computed Radiography (CR) uses a flexible phosphor Imaging Plate (IP) to capture digital images instead of conventional photographic film.

What is a CR device?

This device is an image digitization system designed to acquire and digitize x-ray images from image storage phosphor plates. … A CR system consists of an image reader/digitizer, cassettes containing imaging receptors (photostimulable-phosphor plates), a computer console or workstation, software, monitors, and a printer.

What are CR cassettes made of?

The front of the cassette is made of a low atomic number material (e.g. plastic or carbon) to enable ease in passage of x-rays and the back is made of a high atomic number material (e.g. lead) to reduce backscatter.

What is a CR PSP cassette called?

The PSP IP is loaded into a. cassette that looks like a film/screen cassette. CR cassettes are sometimes called. filmless cassettes.

Is CR a CT scan?

Computed tomography (CT) has become more widely available and computed radiography (CR) has replaced film-screen radiography for canine thoracic imaging in many veterinary practices. … Significantly smaller nodules were detected with CT (P = 0.0007) and no difference in minimum size was detected between CR and films.

What is the function of the bar code in the CR cassette?

B, Barcode label on the CR cassette allows matching of the image with the correct patient.

What is CR and CT?

Both DR and CR modalities produce a 2D image of the object. In contrast, CT systems produce a 3D image that is created by taking multiple image ‘slices’ (usually many thousands) at different angles around a single axis of object rotation.

What are the advantages of computed radiography?

Advantages of computed radiography compared with conventional film/screen combinations include improved contrast resolution and postprocessing capabilities. Computed radiography’s spatial resolution is inferior to conventional radiography; however, this limitation is considered clinically insignificant.

What is difference between cassette and cassette less digital radiography?

Both, conventional image and cassette-based digital radiography use a cassette to capture the image. However, cassette-based digital radiography uses a phosphor plate which is placed inside the cassette whereas conventional radiography uses a film is placed inside a cassette, which contains an intensifying screen.

What are the advantages and disadvantages of computed radiography?

CRDRHigher risk of overexposureLower risk of overexposureSuitable for low or moderate workflowIdeal for high workflow

Article first time published on

What is Phosphorimager?

Amersham Typhoon IP Phosphorimager, GE Healthcare The Typhoon IP is an extremely sensitive laser scanner that detects, documents, and quantifies radiolabeled proteins and nucleic acids.

How many times can we use the CR cassette?

Conclusions: The findings of this study revealed that even though a slight deterioration occurred after the first exposure, each plate can be used up to 200 times. Further studies are required to reach a more concrete conclusion.

What are PSP plates made of?

In PSP systems, the radiographic image is recorded on a thin sheet of plastic known as the imaging plate. The imaging plate consists of several layers (Figure 4-4): A protective layer. This is a very thin, tough, clear plastic that protects the phosphor layer.

What is the element inside the IP of CR cassettes?

The reader opens the cassette automatically; the IP is removed to be scanned by a helium neon laser beam. This process sets the stored energy free as visible light with a wavelength different from that of the laser.

When was computed radiography introduced?

Introduced in the 1980s by Fujifilm Medical Systems, computed radiography (CR) was initially limited to a few select veterinary colleges and specialty private veterinary practices because of high cost.

What is mammography cassette?

Procedures. The two types of imaging currently used for mammography are. Screen-film mammography where x-rays are beamed through the breast to a cassette containing a screen and film that must be developed. The image is commonly referred to as a mammogram.

Why is the film in the lightproof cassette?

The Role of X-ray Cassettes in Radiographic Procedure The cassette acts as a light-proof container in which films or imaging plates are placed for exposure to radiation. For the technologists, the cassette ensures that the highest-quality image will not be compromised by outside light.

What is CT technology?

A computerized tomography (CT) scan combines a series of X-ray images taken from different angles around your body and uses computer processing to create cross-sectional images (slices) of the bones, blood vessels and soft tissues inside your body. CT scan images provide more-detailed information than plain X-rays do.

What is computed radiography Slideshare?

• Computed Radiography is a digital image acquisition process that produces images that have much better contrast than a Conventional X-ray film-screen system.

How does digital radiography differ from traditional radiography?

Digital X-rays are like the digital cameras we have today. They still use X-rays as the standard X-rays; the only difference is that their sensors are connected to a computer and not a film. This enables the modern X-ray to capture clearer and more accurate images as compared to its predecessor.

How are CR plates erased?

When the plate is exposed to ionizing radiation, photostimulable phosphor stores the latent image. … These electrical signals are processed and converted to a digital image. The stored information on the plates can be erased by exposing it to room-level fluorescent light, and then these plates can be reused.

What is the S value in CR?

S-values or “sensitivity” values represent the numeric value of exposure received by the receptors in the digital system. This represents a key value in monitoring that a quality radiograph is obtained with the least amount of dose to the patient.

What does Computed Radiography use as its image receptor?

Computed radiography (CR) is the use of photostimulable phosphor as an image receptor. The image receptor is held in a similar casing (cassette) to that of the traditional film screen.

What is the principal difference between screen film radiography and CR?

What is the principal difference between screen-film radiography and CR? has longer wavelength than the emitted light. You just studied 37 terms!

What is DX in radiology?

The Digital X-Ray (DX) Image Information Object Definition specifies an image that has been created by a digital projection radiography imaging device.

What portion of the CR imaging plate protects the plate from unwanted light and background radiation?

The conductive layer and light shield layer both help to protect the phosphor layer from unwanted light and background radiation.

Why is digital radiography better?

Better Image Quality Digital x-rays provide a much higher image quality than that of traditional film. … Images can be zoomed or the contrast can be adjusted for a better view. A plus for DDR machines is that they provide over 200 shades of grey while the traditional x-rays had just between 16 to 25 shades of grey.

Which is better between the conventional computed and digital radiography in terms of image acquisition?

Digital CR provides better image quality by conventional radiography. The patient’s was blocked loss of data. The Digital CR does not need additional space for archiving.

What kind of detectors are used in CT scan?

Solid State Crystal Detectors are also called scintillation detectors because they use a crystal that fluoresces when struck by an x-ray photon. The photodiode is attached to the crystal and transforms the light energy into electrical (analog) energy.

What is a tomographic image?

1 Introduction. ¯ Tomography is a non-invasive imaging technique allowing for the visualization of the internal structures of an. object without the superposition of over- and under-lying structures that usually plagues conventional projection images.

What is barium Fluorohalide?

CT scanner. Barium fluorohalide with europium is used. As the phosphor that absorbs the x-ray energy in the CR plate. When a CR plate is inserted into the reader for processing, the phosphor is scanned with a. Laser light.
