Armored cable (Type AC) and metal clad cable (Type MC) provide a fast and efficient way of wiring both new construction and remodeling work. Their flexible metal armor provides mechanical protection of the electrical conductors while enabling them to bend around corners.

What is the difference between MC and BX cable?

They’re very similar in most regards, but there is one big difference between the two cables. In the electrical world, AC or BX cables do not come with a ground wire while MC cables do. … Both are essentially just names for armored cable.

Where is MC cable required?

Type MC cable installed on the bottom of floor or ceiling joists must be secured at every joist and not be subject to physical damage [Sec. 330.15].

What is Type AC cable used for?

This standard covers the installation of Type AC and Type MC cables, which are used for electrical wiring for residential, commercial and industrial occupancies. It also includes information on fittings and other accessories necessary for a quality installation of these cable systems.

What is MC wire?

A Metal Clad Cable, also referred to as MC Cable, is a corrosion-resistant metal cable containing insulated copper or aluminum connectors.

What's better BX or Romex?

Romex cables are about 25% cheaper than their BX counterparts. A BX is difficult and heavy to handle. Romex cables are light and have a slippery coating that enables them to be easily pulled through holes. BX cables are safer and protect against any accidental penetrations.

Is MC cable suitable for outdoor use?

These cables can be installed either indoors or outdoors and in exposed and concealed locations. They can be direct buried, where identified for such use. … Type MC cable with a nonmetallic jacket can also be used in a wet location.

Is BX cable legal?

BX is accepted by the National Electrical Code (NEC). Older BX cables without an internal bonding strip are not accepted by NEC.

What is the difference between BX and AC cable?

BX became the registered trade name of AC Cable distributed by General Electric who had acquired Sprague Electric. The biggest difference between the two cable systems is that MC has full size ground wire while AC uses a combination of the jacket and a thin bonding strip or wire to function as the equipment ground.

What is MC AP cable?

MCAPcable is Type MC cable constructed with THHN copper insulated circuit conductors and interlocked armor that is listed and identified for grounding. … The dual use is permitted because the armor of MCAP cable is listed and identified as a suitable equipment grounding path, unlike conventional MC.

Article first time published on

Is MC cable grounded?

MC-Stat® MCI-A cable has a full-sized insulated copper conductor as a second equipment grounding means for healthcare applications.

When should you use MC cable?

Type MC cables are widely used in 600 volt and MV power, lighting and fixture whip control applications. They are permitted for use on services, feeders and branch circuits for power, lighting, control and signaling circuits in accordance with Article 330 and 725 of the NEC.

Is MC cable allowed to be exposed?

Section 330.15 states: Exposed runs of cable, except as provided in 300.11(A), shall closely follow the surface of the building finish or running boards. Exposed runs shall also be permitted to be installed on the underside of joists where supported at each joist and located so as not to be subject to physical damage.

Can MC cable be bundled?

There are roughly ten 12-2 MC cables installed in bundled configuration using nylon tie wraps. These cables are the homeruns for 20-ampere branch circuits. Appreciate your insight.

Why is MC cheaper than Romex?

When it comes to pure MC cable versus Romex cost, Romex is about 25% cheaper than MC cable due to the fewer source materials and lower shipping costs. In terms of installation, Romex can cost more than MC cable if a protective conduit is required.

What type wire is in MC cable?

MC cable contains conductors from 18 AWG through 2000 kcmil for copper and 12 AWG through 2000 kcmil for aluminum. Typical branch circuit Type MC cables have copper conductors with THHN, THHN/THWN or XHHW insulation and are suitable for circuits up to 600 volts.

How long can you run MC cable?

of every outlet box, junction box, cabinet, or fitting and at intervals not exceeding 6 ft. Type MC cable must be supported at intervals not exceeding 6 ft. Cables installed horizontally through wooden or metal framing members are considered secured and supported where such support doesn’t exceed 6 ft intervals.

Can MC cable get wet?

PVC coated, sunlight resistant, direct burial rated MC cable can be used in a wet location. … General use MC cables cannot be used in wet locations but there are some types of specialty MC cables that can. The most common is the PVC coated, sunlight resistant, direct burial listed MC cable in the image.

Is MC waterproof?

STAYING SAFE WITH THICK BITUMINOUS COATINGS FROM MC With MC’s thick bituminous coatings, you are always on the safe side. They adapt perfectly to the substrate or soil and, with polymer-modified bitumen, even protrusions, light shafts and abutments can be waterproofed – quickly, simply and reliably.

Can you bury MC in concrete?

Can I install Type MC in concrete or against concrete or mortar? A. Yes, if the cable is listed for the application. Type MC cable is available with an outer PVC jacket and is permitted to be installed in parking decks, concrete pours and for direct earth burial if it is identified for such use.

When was BX wiring used?

BX wiring (also known as armored cable) is the 2nd generation of wiring used in homes. It first appeared in the 1903 National Electrical Code (NEC) book. It became popular in the 1920s, and it was the main wiring type by 1932.

Is BX wire copper or aluminum?

Armored cable, referred to as Type AC cable or BX Electrical Cable is one of the original styles of flexible conduit used as an alternative to pipe and wire installations. … A 16 AWG (American Wire Gauge) bare aluminum bond wire is used along with the armor as the ground path.

What does BX wire mean?

2) BX: BX is also known as Armor Clad or Flexible Metal Conduit cable. BX contains one or more individually insulated “hot” conductors, one individually insulated neutral conductor, and a ground wire, which may or may not be individually insulated. BX is also known as Armor Clad or Flexible Metal Conduit cable.

What is the difference between MC and Greenfield?

Flexible metal conduit (FMC) is commonly called “Greenfield.” The main difference between MC cable and FMC is that FMC doesn’t have the insulated wires pre-installed; you have to pull them through instead. … It also allows you to add wires in the future, something you can’t do with MC cable.

Can BX cable be used as ground?

In the case of old steel-clad armored cable (BX), it’s still legal to use the metal shield as a ground, but I wouldn’t do it. … However, you may not be able to get the GFCI breaker to hold, because old circuits tend to have some ground leaking.

Is BX wiring bad?

BX is much safer If there is an issue it is inside the flexible conduit and that metal conduit is quite a bit of protection. Replacing breakers may or may not be possible with your existing panel and again your wiring is in conduit so I would not be concerned.

What is HCF MC cable?

The U.S. Patented* MC Luminary HCF® is a hospital grade cable for patient care areas for LED and Fluorescent dimming, utilizing redundant ground per NEC 517.13.

Where is hospital grade MC cable?

Branch circuits in areas of patient care in hospitals, nursing homes, outpatient facilities, dental offices, clinics and medical centers (other than emergency, life safety or critical care locations), Places of Assembly, under raised floors, above suspended ceilings, environmental air-handling spaces, exposed or …

Can MC cable be painted?

The quick answer is “yes,” but let’s cover some of what you’ll need to know first. Painting the armor does not violate the National Electric Code (NEC), however, this process can be time consuming and also create more cleanup on the job-site utilizing pre-painted armor saves time and labor.

Is MC cable conduit?

Type MC armored cable can be installed in cable tray, racks, hangers, or as a cost-effective replacement for conduit and wire where specified per the National Electrical Code (NEC). … We’ve updated our labor and material cost-savings chart.

How often does MC cable need to be supported?

According to NEC Article 330.30, MC cable must be supported and secured at intervals of 6 feet or less (unless routed through a framing member) and cables containing four or fewer conductors sized no larger than 10 AWG must be secured within 12 inches of every termination.
