An arc flash boundary is the distance from the equipment in question to the point where the energy that would be present in an arc flash is 1.2 cal/cm2. This is the level at which it will cause only second-degree burns rather than third-degree.

How do you calculate arc flash distance?

The arc flash boundary is calculated to 1.2 calories/cm2 of incident energy. That’s the distance where a worker without appropriate PPE would receive second-degree burns. Sometimes this boundary is the furthest one from the exposed equipment, other times the limited approach boundary is the furthest out.

What is the distance to live electrical parts for the flash protection boundary?

Best practice is to stay 12” or more away from the hazard. This area should only be entered by qualified persons and the qualified person should be wearing Personal protective Equipment (PPE). Any work done within the 12” is considered energized work and requires an Energized Electrical Work Permit.

How much space do you need to protect yourself from arc flash?

Generally 18 inches is assumed to be the distance between a worker’s face/chest and the arc-flash.

What is electrical working distance?

Basically, the working distance is the distance between you and the point of origin of an arc flash. The point of origin for an arc flash will typically be inside a piece of electrical equipment, at an energized conductor or bus. A typical working distance for low voltage equipment might be 18 inches.

How do you find arcing distance?

1. Divide the chord length by double the radius.
2. Find the inverse sine of the result (in radians).
3. Double the result of the inverse sine to get the central angle in radians.
4. Once you have the central angle in radians, multiply it by the radius to get the arc length.

What is minimum approach distance?

The word is actually an acronym that stands for minimum approach distance, which is the calculated safe working distance that provides worker protection when working on or in the vicinity of energized lines and equipment.

What is Category 2 arc flash?

In PPE CAT 2, workers need the following clothing: Required Clothing: Arc Rated Long Sleeve Shirt and Pants or Arc Rated Coverall with minimum arc rating of 8 cal/cm. 2. Required AR Face and Head Protection: Arc Rated Arc Flash Suit Hood or AR Face Shield, Sock Hood/Balaclava with minimum arc rating of 8 cal/cm. 2.

What does HRC 1 mean?

HRC (Hazard/Risk Category): The chart, based on specific job tasks, ranges from HRC 1 (which is low risk and allows for 100% treated cotton), up to HRC 4 (which is high risk and requires FR clothing with a minimum arc rating of 40).

What is the biggest danger from seeing an arc from arm's distance?

Worse, clothing can be ignited and the synthetic fabrics can be melted to skin. Other arc flash injuries include nerve damage, hearing loss, blindness, and cardiac arrest. Arc flashes can destroy property and lead to the death of personnel present within the arc flash boundary.

Article first time published on

What are the four limits of approach boundaries?

• Flash protection boundary (outer boundary) The flash protection boundary is the farthest established boundary from the energy source. …
• Limited approach boundary. …
• Restricted approach boundary.

What is the standard distance of the flash hazard boundary onset of 2nd degree burn *?

“… a distance from a prospective arc source within which a person could receive a second degree burn if an electrical arc flash were to occur.” Since 1.2 cal/cm2 is widely accepted as the minimum energy that can cause the onset of a second degree burn, the AFPB is the minimum distance required to reach this level.

What is the preferred setback distance from overhead wires?

Stay at least 10 feet away from overhead wires during cleanup and other activities.

How do you lower arc flash rating?

Arc flash energy can be reduced by (in order of effect): decreasing the trip times; reducing fault currents; and increasing the worker distance. There are many methods and techniques that the technician or engineer can use to reduce the incident energy levels.

What is usually used to determine safe working distances?

The working distance printed on an arc flash warning label was determined by the arc flash incident energy analysis performed by an electrical engineer. Default working distances are determined by using IEEE 1584 Table 3 which is based on the voltage class of the equipment. See figure 3.

How is incident energy calculated?

The incident energy is calculated based on the available bolted fault current, system voltage, the clearing times of the associated over-current protective devices and the individual parameters of the electrical distribution system.

What is the minimum approach distance for 345 kV?

Over 345 kV to 750 kV 16 ft. Over 750 kV to 1,000 kV 20 ft.

What is the overhead powerline approach distance for a 1kv power line?

Voltage (kV)Minimum clearance distance (feet)>50 to 345 kV10 ft>345 to 750 kV16 ft>750 to 1,000 kV20 ft> 1,000 kV*

What is the safe distance from 11kV power lines?

As per the Indian Electricity Act, buildings should maintain a horizontal distance of 1.2 metres from 11kV lines and 4 metres from 66kV lines.

What is clearance distance?

Clearance is the shortest distance in air between two conductive parts. … Creepage distance means the shortest distance along the surface of a solid insulating material between two conductive parts.

How much voltage is an arc?

In general, arc faults only occur in systems that are 120 volts or higher, but that is not a hard rule. If the conductors are very close together, even a lower voltage level can create a small arc flash.

How far can 50kV arc?

FPL Power Line VoltagesOSHA Minimum Approach Distance* (OSHA 1926.1408 Table A)Over 50kV to 200kV15 feetOver 200kV to 350kV20 feetOver 350kV to 500kV25 feetOver 500kV to 750kV35 feet

How is HRC level calculated?

An HRC level is determined by the minimum amount of calories per square centimeter (ATPV or Cal/cm2). Any treated garment must pass through with a 50% probability of a 2nd or 3rd degree burn occurring, which is how the protective level of the treated clothing is determined.

Is Cat 2 the same as HRC 2?

NEW Term: PPE Category (CAT)Former Term: Hazard Risk Category (HRC)Minimum Arc Rating228.03325.04440.0

What is Cal cm2 mean?

Calories per Centimeter Squared (cal/cm2): This is a number identifying the amount of energy that can be delivered to a point at a particular distance from an arc flash. Once this value is known, the ATPV rating of the flash clothing required for work at that distance from the potential flash hazard is also known.

What is cat 0 PPE?

HRC PPE Category 0: < 1.2 cal/cm2 Clothing – Long sleeve shirt and long pants made of nonmelting or untreated natural fiber (i.e., untreated cotton) with a fabric weight of at least 4.5 oz./square yard.

What does NFPA 2112 mean?

NFPA 2112: Standard on Flame-Resistant Clothing for Protection of Industrial Personnel Against Short-Duration Thermal Exposures from Fire.

What are the three shock protection boundaries?

There are three electrical shock hazard boundaries depending on the voltage of the appliance and termed the limited approach boundary, the restricted approach boundary, and the prohibited approach boundary.

How do you stop arc blast?

1. De-energize electrical equipment.
2. Wear suitable Personal Protective Equipment (PPE)
3. Keep at a safe distance.
4. Reduce the energy output from an incident.
5. Carry out a risk assessment.
6. Train on-site workers to control risks and interrupt faults.

How are arc faults prevented?

1. Perform a hazard analysis. …
2. Reduce available fault current. …
3. Shorten clearing time. …
4. Adopt remote operation. …
5. Predict and prevent faults. …
6. Redirect blast energy.

Which one is used for avoid arcing?

Common devices used to prevent arcs are capacitors, snubbers, diodes, Zener diodes, varistors, and transient voltage suppressors. Contact arc suppression solutions that are considered more effective: Two-wire contact arc suppressor.
