The compressor’s discharge temperature should be measured about 1 to 2 inches away from the compressor on the discharge line. This discharge temperature should never exceed 225°F. Carbonization and oil breakdown can occur if compressor discharge temperatures exceed 225°.

How do you fix high temperature discharge?

Discharge temperature is greatly affected by the compression ratio, the larger the compression ratio, the higher the discharge temperature. Reducing the compression ratio can significantly reduce the discharge temperature, including increasing the suction pressure and reducing the discharge pressure.

What is high discharge pressure on a carrier unit?

One common cause of high discharge pressure is the cooling medium (air or water) flowing across the condenser: either there is not enough or the temperature of the cooling medium is too high. … The noncondensables will take up space in the condenser, leaving less room for the condensing of the refrigerant.

What is discharge temperature of heat pumps?

The most widely quoted rule of thumb is the 100°-110° over ambient discharge rule. This guideline states that a properly charged unit will have a discharge line temperature of 100°-110° above the outdoor temperature. If the discharge line is too hot, add refrigerant (if the charge is the issue and not another problem).

What causes high liquid line temperature?

High compression ratios from the low evaporator pressure will cause high heat of compressions, thus high discharge temperatures. High superheats. Both evaporator and compressor superheats will be high. This is caused by the TXV, evaporator, and compressor being starved of refrigerant from the liquid line restriction.

Is discharge high or low side?

The high side, or discharge line, will be the line connected to the compressor from the bottom or lower position. It will not be wrapped in insulation and will be warm to the touch. This is where freon exits the compressor as a liquid.

What causes high discharge superheat?

Other causes of high Discharge Superheat are a kinked or restricted liquid line, a restricted filter drier, a restricted Accurator piston or Accurator strainer or an Electronic Expansion Valve (EEV) under feeding the evaporator. Restricted condenser air flow can also contribute to high Discharge Superheat.

What is saturated discharge temperature?

the saturation temperature of the refrigerant (the temperature at which the refrigerant changes from a liquid state to vapor. This is the same as its boiling point. For water at sea level, the saturation temperature is 212F. The saturation temperature of a liquid increases as pressure increases.

How do I know my discharge is superheat?

The discharge superheat is calculated the same way as any other superheat/ subcool on a system. By measuring the discharge superheat you can subtract the suction superheat and that then leaves you with a figure of how much superheat the compressor has given through compression and mechanical /electrical inefficiencies.

What is discharge pressure level?

Discharge pressure (also called high side pressure or head pressure) is the pressure generated on the output side of a gas compressor in a refrigeration or air conditioning system. … An extremely high discharge pressure coupled with an extremely low suction pressure is an indicator of a refrigerant restriction.

Article first time published on

What does the discharge line do?

DISCHARGE LINE – Line connecting compress outlet to the condenser inlet. DRIER – A device containing a desiccant placed in series, usually in the liquid line, to absorb and hold excess moisture. Usually called receiver-drier.

What is low discharge superheat?

A low discharge superheat alarm indicates that the compressor is flooding with the refrigerant. This is mostly because the expansion valve is overfeeding to the evaporator or due to a faulty actuator.

What is a high superheat?

Excessive or high superheat is an indication of insufficient refrigerant in the evaporator coil for the heat load present. This could mean that not enough refrigerant is entering the coil or this could also indicate an excessive amount of heat load on the evaporator coil.

At what temperature does R134a condense?

For a simple circuit, using the working fluid Refrigerant R134a, evaporating at −5°C and condensing at 35°C, the pressures and enthalpies will be as shown in Fig. 2.3: Enthalpy of fluid entering evaporator =249.7 kJ/kg.

What is saturation temperature of r410a?

A normally operating R-410A system with the same condensing temperature of 120 degrees and a 45 degree evaporator saturation temperature will have a high side pressure of 418 psig and a low side pressure of 130 psig.

How do you find the actual saturated temperature?

You can calculate the saturation temperature with the following steps or use the simpler alternative outlined after. –Step 1: Measure the system’s temperature in degrees Celsius. Convert it to Kelvin by adding 273 degrees. –Step 2: Use the Clausius-Clapeyron equation to calculate the saturation pressure.

Do refrigerant lines get hot?

When the system is operating, the large insulated suction line should be cold to the touch and sweating at any point where there is no insulation. The smaller uninsulated liquid line should be warm to the touch after the system has been operating for 10 or 15 minutes.

Does refrigerant get hot?

When the Freon gas is compressed, its pressure rises, making it very hot.

Why is my suction line warm?

The external suction line running hot means it’s running on heat mode. The real suction line is inside the unit and runs between the reversing valve and compressor, that part shouldn’t be hot at any time.

How do you calculate discharge pressure?

So, the discharge pressure is equal to the suction pressure plus the pump’s design pressure. The discharge pressure of the pump should be approximately equivalent to the total dynamic head (TDH) required by the system (tanks, pipes, elbows, valves, flanges and fittings).

What is low head pressure?

Low head pressure may occur simulataneously with high pressure on the suction side of an air conditioner, heat pump or refrigeration system compressor system. If the system is continuing to cool it may be doing so at reduced capacity, observed as a loss of up to ten degrees of temperature drop across the coil.

Why is my liquid line freezing?

What Causes Your Air Unit To Be Frozen. The main reason why your AC lines are freezing is because your evaporator coils are getting too cold. The evaporator coil is filled with refrigerant which cools the air in your HVAC system. … The ice can eventually accumulate on the refrigerant line.

What makes a liquid line cold?

A notable sign that you have a liquid line restriction is low pressure in your evaporator. Liquid line restrictions can be caused by a restricted filter-drier, a restricted thermostatic expansion valve screen, a kinked liquid line, a bent lower condenser coil, or an oil-logged capillary tube.

What happens if superheat is too high?

Too high of a superheat can cause the heat of compression to increase, causing the temperature at the discharge valves to increase. If the temperature increases beyond its safe operating temperature, it will cause damage to the compressor.

What is considered high subcooling?

Subcooling on systems that use a thermostatic expansion valve (TXV) should be approximately 10F to 18F. Higher subcooling indicates excess refrigerant backing up in the condenser.
