Magnetron Ignition – This solid state ignition system introduced by Briggs & Stratton in 1982 eliminated the points and condenser system, the performance of which steadily degraded between required periodic maintenance service.

Do old Briggs and Stratton engines have points?

Since 1982, Briggs & Stratton engines have used a solid-state ignition. Models built before 1982 employed a magneto, points and condenser system to generate spark for the spark plug. If you are using an older model Briggs & Stratton engine that has no spark, you might need to set the points.

What is the points gap on a Briggs and Stratton engine?

Replacement Part TypeBriggs & Stratton Spark Plug Part NumberSpark Plug GapExtended Life Series® OHV Spark Plug Platinum (Replaces Champion RC12YC)696202 5066 (5066D, 5066H).030”Resistor Spark plug – hotter spark (Replaces Champion RC14YC)496018S 5092.030”Resistor692051.020”

How do I tell how old my Briggs and Stratton engine is?

1. The first two digits (99) denote the year of manufacture. …
2. The next two digits (01) are the month of the year, which is January.
3. The following two digits (15) are the day of the month. …
4. The final two digits designate the plant and assembly line.

When did they stop using ignition points?

All cars up until 1975 or so used a point type ignition system. After 1975, most cars went to electronic ignition systems. Basically, electronic ignitions were “improved points.” The principles were the same and it simplified the ignition system.

How do you tell what year your engine is?

The engine will have a alphanumeric casting number on the passenger side (right side) of the block, under the heads. The first letter of the code identifies the decade (C=1960s, D=1970s, E=1980s), the second digit in the code identifies the specific year.

Do lawn mower engines have points?

Instead, the switching is performed by a pair of transistors. Magnetron ignition systems are so reliable that they have replaced breaker point systems in all lawn mower engines produced by Briggs & Stratton as well as in those produced by other manufacturers.

What does the second set of engine numbers represent?

The first number you find will be the model number, the second number is the engine type and the third number is the code number.

How old is my mower?

By locating the serial number tag on your machine, you can easily determine your mower’s age. If you have the owner’s manual for your mower, you can also check the date printed on the inside of the manual. This date should be one year after the mower’s manufacture date.

What is the gap on a Briggs and Stratton Magneto?

Replacing Ignition Coils or Armatures Your engine repair manual will provide the proper gap for your engine. Common armature gap ranges are . 006 – .

Article first time published on

What are engine points?

A contact breaker (or “points”) is a type of electrical switch, and the term typically refers to the switching device found in the distributor of the ignition systems of spark-ignition internal combustion engines.

Do all spark plugs come pre-gapped?

Not always. In the past, it was necessary to gap spark plugs, but today spark plugs are usually pre-gapped. It is advisable to double check that the gap is correctly set to the vehicle’s recommended setting when installing spark plugs.

Do lawn mower spark plugs need to be gapped?

Summary. Lawnmower spark plugs can come pre-gapped, but this depends on the manufacturer. However, in most cases, the gap can be too small or too big, which can lead to ignition problems. … Spark plugs need to be pre-gapped to ensure proper ignition of the air and fuel mixture.

What is the gap on Autolite spark plugs?

001” is more than important. One of locations on a spark plug where measurement is critical is the gap. The location between the center electrode and the ground electrode. If the gap is too small, the flame may not have the room it needs to expand properly.

What year did GM go to electronic ignition?

Electronic ignition was first used on Chrysler production vehicles in 1972 with GM and Ford following in some large V-8 applications in 1974.

What year did Ford stop using points distributors?

All FE-equipped vehicles (with rare exception) had a traditional points-style distributor and ignition system from 1958 until 1974.

What year did electronic ignition come out?

Electronic ignitions were initially developed in the late 1940s and were offered as an option on some GM vehicles in the early 1960s. FIAT offered the first standard-fit electronic ignition in the ’68 Dino, but that wasn’t sold in the US; the 1971 Jaguar XJ, which also had it, was.

How do I know if my points are bad?

1. Vehicle not starting. If your vehicle will not start, it is possible there is a problem somewhere within the points and condenser. …
2. Engine will not fire. …
3. Engine runs rough.

Do spark plugs fire when points are open or closed?

As the engine rotates, the distributor shaft cam turns until the high point on the cam causes the breaker points to separate suddenly. Instantaneously, when the points open (separate) current flow stops through the primary windings of the ignition coil.

How do I know if my points are working?

Test for continuity between the block and the stationary point attached to the distributor plate. Rotate the engine until the points are closed. Use the multi-meter to test for a good connection between the points. A slight gap when the points are supposed to be closed will keep your machine from running.

How do you read GM date codes?

Read the next four digits in the code, which will be all numbers. This refers to the date that the engine was cast. The first two numbers are the month, and the last two are the day. For example, if the numbers read 0107, then the engine was cast on January 7.

What horsepower is my Briggs and Stratton engine?

Where can I find my engine’s horsepower or torque rating? You can find the gross horsepower or torque value labeled on your engine. To find an engine’s horsepower, look for a number with “HP” or “cc.”

What year is Craftsman mower?

It is a Craftsman model number 502.255070. You can tell the date of manufacture for a tractor with the serial number. The first 2 digits of the serial number are the month of manufacture. The 2nd 2 digits are the day of the month. The 3rd 2 digits of the serial number are the year of manufacture.

What year was the Craftsman Ys 4500?

The Craftsman YT 4500 54” Lawn Tractor ($2,000) is the company’s top-of-the-line residential mower for 2011.

What year is Craftsman LT2000?

Craftsman LT2000 – 2004-2006. Similar to the LT1000, but priced a bit higher, these machines have a few extra desirable features like a slightly higher seat, cast-iron front axle, a little more powerful engine, frequently with full-pressure lubrication and an oil filter, heavy-duty deck, and bigger rear tires.

What do the numbers on a Briggs and Stratton engine mean?

The first digit after the displacement indicates the BASIC DESIGN SERIES, relating to cylinder construction, ignition, general configuration, etc. C. The second digit after the displacement indicates ORIENTATION OF CRANKSHAFT. … The last digit indicates the TYPE OF STARTER.

Where was my Briggs and Stratton made?

Briggs & Stratton began manufacturing in Milwaukee, WI, in 1908 and today more than 85 percent of Briggs & Stratton engines are made stateside at plants in Alabama, Kentucky, Georgia and Missouri using U.S. and global parts.

What year is my Tecumseh engine?

Look for the engine model number. You may find it stamped on the blower housing or on an engine identification label located on the front or top of the engine or under the engine cover. Find the date-of-manufacture code, usually found near the abbreviation “D.O.M.” or at the end of the engine model number.

Should magneto touch flywheel?

The magneto should not touch the flywheel. In fact, you have to adjust the gap between the coil and flywheel magnets so that the flywheel magnet lines up directly with the magnetic coil and feeler gauge tool.

How does a magneto with points work?

The magneto is a self-contained generator of high voltage that provides ignition to an engine through spark plugs. … The moment the contact points open, a rapid magnetic flow generates a high voltage in the secondary coil, which ignites the spark plug, thus firing the engine.

What causes a magneto to fail?

The voltage generated across magneto coils is quite high, in the order of 20,000 volt if no spark plugs are in place. … The high voltage will simply arc across the gap. The gap will widen as the wire ends melt further apart and soon the adjacent turns will be affected so the coil will eventually fail.
