Locate the condensate drain access point outside your home or near the indoor air handler enclosure. You should see a small vertical vent extension as part of the piping. The vent is located above the point where the line exits your air handler. Open the plug on top to access the drain lines.

How do you know if your AC drain line is clogged?

1. Musty, moldy smell near your indoor unit or in air from the registers/vents.
2. Standing water near the indoor unit.
3. Water damage in areas near the indoor unit.
4. AC system is not cooling your home.
5. AC system shuts down or doesn’t turn on.

Where is my outside AC drain line?

Find your AC drain line. Most AC drain lines are located outside, near the condenser unit. Push the stiff, thin brush into the end of the drain line. This might clear any clogs located near the end of the drain line.

How far from house should AC drain line?

The condensate drain line is a white circular drain pipe not less than 3/4 of an inch in diameter. The problem that I see often as a Licensed Home Inspector is that most a/c condensate drain lines are routed outside, which is ideal, but stop or terminate 2 to 3 inches from the homes foundation.

Can condensate drain to ground?

Both air conditioning condensate and refrigeration condensate are on the list of allowable discharges, provided that such water is distilled pure water taken from the atmosphere. However, any cleaning water or washwater can not be discharged to the ground, but must be captured for disposal in the sanitary sewer system.

What causes AC drain line to clog?

According to experts, clogging occurs when the moisture that drips off your evaporator coil carries dirt, small debris and other airborne particles into the condensate drain. The dirt and airborne particles will eventually build up and cause a clog.

How do I keep my AC drain line clear?

1. Find and inspect the condensate line in your home or garage. …
2. Check the outside unit to make sure the drain pipe is not obstructed. …
3. If possible, use a wet-dry shop vac to remove any excess water from the drain pan and condensate/drain line. …
4. Add a ½ cup of vinegar to the condensate/drain line.

How much water should come out of AC drain line?

It’s completely normal for your AC to drain 5-20 gallons of water outside of your home (via the condensate drain). It’s NOT normal for your AC to drain any amount of water inside your home (around your indoor AC unit).

Should AC drain line have trap?

Your a/c system needs to have two drain lines. … As you can see on the main drain line, there is a P-trap and the vent pipe is after the P-trap allowing for proper air and water flow. The secondary drain line needs to be pointing downward toward the drain pan, but other than that, it is properly installed.

Where is the drain on a window AC unit?

On constantly draining units (usually older or very large units) the hole is generally underneath the exterior portion of the unit and may be very small. Window air conditioners designed to retain water may have a hole on the side instead, so when the water reaches a given level it drains away.

Article first time published on

Should my exterior AC drain pipe be dripping water?

Under normal conditions, the exterior AC condensate drain pipe should only drip water or produce condensation while the air conditioner is turned on. The small puddle of water this process creates should dry up quickly in warm weather.

How much does it cost to unclog AC drain line?

Clogged Drain Line To flush the line or repair it can cost anywhere from $75-$250. In the case that the evaporator coil needs replacing, you are would pay between $400 to $950.

Can you put Drano in AC drain line?

In theory Drano could unblock a clog but this is designed for food and grease, which you aren’t going to find in your AC drain pipes. So just like you could pop the cap off a bottle of beer using a hammer in just the right way, it’s not the best way to open a bottle of beer or the best use of a hammer.

How does a condensate drain work?

How a condensate drain pan works is by collecting this water as it drips from your air conditioner’s evaporator coils. The condensate pan is attached below the evaporator coils. It must be correctly fitted to catch moisture without leaks. Moisture flows to the condensate drain line and out of your home.

How many drain lines does an AC have?

The main air unit is equipped with two condensate drain outlets: a primary drain for conveying water outside and a secondary drain as a backup, in case the primary becomes blocked or congested.

Should there be water in AC drain pan?

According to experts, small amounts of water in your AC drip pan are normal. When warm air passes over the cold coils, the water vapor condenses into water. This water will then travel down a small pipe into the drip pan. … However, if the pump is broken, the water will overflow.

Is it OK to have water in the AC drip pan?

As a homeowner, you know finding water somewhere it’s not supposed to be is usually a bad sign. However, when it comes to your air conditioner’s drip pan, also known as the drain pan, the presence of water is perfectly normal… but only if it’s flowing out of the pan.

Do all window air conditioners drip water?

All room air conditioners drip — or at least they should. However, drips in the wrong place or the wrong volume of dripping water may be a sign of a problem with the air conditioner. Find out how much air conditioner leaking water is normal, and when it signals trouble.
